0.6/1kv Quadruplex Drop AAC Overhead Cables 2 1/0AWG Mustang Palomino Shetland

0.6/1kv Quadruplex Drop AAC Overhead Cables 2 1/0AWG Mustang Palomino Shetland image

Get Latest Price Request a quote

Product Details

Model NO.

JKLYJ

Current

DC & AC

Insulation Material

XLPE

Sheath Material

No Sheath

Material Shape

Round Wire

Wire Core Material

AAC

Certification

ISO, CCC

Model

Jkyj ABC

Brand

Hongda

Cable Type

ABC

Standard

IEC UL

Transport Package

Drum or Roll

Specification

50mm

Trademark

HONGDA

Origin

China

HS Code

8544492100

Production Capacity

20km/Day

Product Description

0.6/1kv quadruplex drop AAC Overhead Cables 2 1/0AWG mustang palomino shetland

ABC Cable are overhead power lines using several insulated phase conductors bundled tightly together, usually with a bare neutral conductor. They can improves safety and reliance of electrified wire netting.

Type and Application

Type	Application
Duplex Service Drop	To supply 120 volt aerial service for temporary service at construction sites,outdoor or street lighting . For service at 600 volts or lower at a conductor temperature of 75°C maximum.
Triplex Service Drop	To supply power from the utility’s lines to the consumer’s weatherhead.For service at 600 volt or less (phase to phase) at a conductor temperature of 75°C maximumfor polyethylene insulation 90°C maximum for crosslinked insulation.
Quadruplex Service Drop	Used to supply 3 phase power, usually from a polemounted transformer, to the user’sservice head where connection to the service entrance cable is made. To be used at voltages of 600volts or less phase to phase and at conductor temperatures not to exceed 75°C for polyethyleneinsulation 90°C maximum for crosslinked polyethylene(XLPE) insulated conductors.

Aerial bundle cable / Triplex Service Drop-Aluminum Conductor, ASTMB-232
Code Name	Phase Conductors(AAC)				Bare Neutral(AAAC)		Weight			Ampacity
	Size/no of wires	Insulation thickness	Nominal Diameter		Size/no of wire	rated strength	XLPE	Aluminum	Total
		Insulation thickness	Bare	OD		rated strength	XLPE	Aluminum	Total
		mm	mm	mm		kg	kg/km	kg/km	kg/km	A
Fulgur	3/0-19	1.52	11.9	15	1/0-7	2023	168	650	819	242
Balanus	3/0-19	2.03	11.9	16	1/0-7	2023	216	650	868	242
Stonecrab	3/0-7	1.52	11.8	14.8	3/0-7	3080	165	752	917	242
Flustra	3/0-7	1.52	11.9	15	3/0-7	3080	168	752	920	242
Crisia	3/0-19	2.03	11.9	16	3/0-7	3080	216	752	969	242
Squid	4/0-7	1.52	13.3	16.3	2/0-7	2431	191	820	1011	279
Arca	4/0-19	1.52	13.4	16.5	2/0-7	2431	192	820	1012	279
Bugula	4/0-19	2.03	13.4	17.5	2/0-7	2431	246	820	1066	279
Kingerab	4/0-7	1.52	13.3	16.3	4/0-7	3883	191	948	1137	279
Lepas	4/0-19	1.52	13.4	16.5	4/0-7	3883	192	948	1140	279
Cassi	4/0-19	2.03	13.4	17.5	4/0-7	3883	246	948	1194	279
