0.6/1kv Overhead Aerial Bundled Conductor Twisted Cable Self-Supporting 4X25mm2 NFA2X Cable

0.6/1kv Overhead Aerial Bundled Conductor Twisted Cable Self-Supporting 4X25mm2 NFA2X Cable image

Get Latest Price Request a quote

Product Details

Model NO.

4x25mm2 NFA2X Cable

Application

Overhead

Conductor Material

Aluminum

Insulation Material

XLPE

Material Shape

Round Wire

Range of Application

Flame Retardant

Certification

ISO9001, CE, CCC

Transport Package

Wooden Drum

Specification

4X25mm2 NFA2X Cable

Trademark

OEM

Origin

China(Mainland)

HS Code

8544492100

Production Capacity

500 Kilometer/Month

Product Description

0.6/1kv Overhead Aerial Bundled Conductor Twisted Cable Self-supporting 4x25mm2 NFA2X Cable

4x25mm2 NFA2X Cable Application

Bundle conductor for overhead energy distribution network without and with public lighting. (between pole to pole).

4x25mm2 NFA2X Cable Construction

Conductor

Phase : Stranded All Aluminium conductor (AAC)

Insulation: Extrude of XLPE

Specification

SPLN 42-10 : 1993

Standard: DIN VDE 0276-626

(Other specifications are available upon request)

4x25mm2 NFA2X Cable Parameter

PHYSICAL PROPERTIES					ELECTRICAL PROPERTIES
Cable Size	Insulation Thickness	Approx. Twisted Diameter	Approx. Net.Weight	Max. Conductor Resistance at 20 ºC	Current Carrying Capacity at 35ºC	Calculated Breaking Force
mm2	mm	mm	Kg/km	Ω/km	A	kg
2x10rm	1.2	14	94	3.08	54	322
2x16rm	1.2	16	138	1.91	72	515
4x10rm	1.2	17	187	3.08	54	644
4x16rm	1.2	19	272	1.91	72	1030
4x25rm	1.4	24	423	1.2	102	1610
4x35rm	1.6	27	564	0.868	125	2250

Packing

Steel wooden drum (fumigation)
Cable length in each drum: 1000m/2000m or as per actual cable length requirements.

Drum size:
As per cable length and container size
*In order to quote you accurate price, kindly tell us your needed cable length quantity. Larger quantity, more discount benefit ready for you!

Shipping Port:

Tianjin, Qingdao, or other ports as per your requireents.

Sea freight:
FOB/C&F/CIF quotation are all available.

*For some countries such as Africa countries, middle east countries, our sea freight quotation is much cheaper than clients get from local shipping agency.

Any problem and inquiry pls contact with Tina

We are China 0.6/1kv Overhead Aerial Bundled Conductor Twisted Cable Self-Supporting 4X25mm2 NFA2X Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
