0.6/1kv Nyy Nym 3core 2.5mm2 PVC Insulated PVC Sheathed Nyy Power Cable

0.6/1kv Nyy Nym 3core 2.5mm2 PVC Insulated PVC Sheathed Nyy Power Cable image

Get Latest Price Request a quote

Product Details

Model NO.

NYY 3cores 2.5mm2

Current

DC & AC

Insulation Material

PVC

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Bare Copper Wire

Certification

ISO, CCC, CE, RoHS

Model

Nyy Cu/PVC/PVC

Brand

Hongda

Standard

VDE

Keyword

2.5mm2 PVC Insulated Cable

Insulation Color

Red Yellow Green

Packing

Wooden Drum

Transport Package

Wooden Drum

Specification

3 core, 4core

Trademark

Hongda

Origin

China

HS Code

8544492100

Production Capacity

3000km/Month

Product Description

0.6/1kV NYY NYM 3core 2.5mm2 PVC Insulated PVC Sheathed NYY Power Cable

Construction:

^{NYY Electric Cable}

Application:

^{1. These cables are most suitable for direct burial or for installation on trays or ducts, Where there is a risk of mechanical

damage, armoured cables should be used.

2. For laying in ground along route with large difference of level able to bear external mechanical forces.}

NYY Cables Application Range
The cable is used as power diatribution and transmission line at rated voltage 0.6/kv which can be fixed installed.

N2XY N2XBY N2XFY/RY Cable Application Range
The cable is used in electirc transmission and distribution system

Description
NYY: Stranded copper conductor for single and shaped conductors for multi-core cables. PVC insulated, pvc sheathed cables.
N2XY: Stranded copper conductor for single and shaped conductors for multi-core cables. XLPE Insulated, PVC bedding, unarmored,
PVC sheathed cables.
N2XBY: Stranded copper conductor for single and shaped conductors for multi-core cables. XLPE Insulated, PVC bedding, Steel Tape
Armored, PVC sheathed cables.
N2XFY/RY: Stranded copper conductor for single and shaped conductors for multi-core cables. XLPE Insulated, PVC bedding, Steel
Wire Armored, PVC sheathed cables.

Standard
IEC60502,and BS6346, VDE, AS/NZS,UL,etc or as customer’s request.
Conductors Plain annealed stranded circular (rm) or sector shaped (sm) copper conductor, as per Class 2 of IEC 60228.
Insulation XLPE material and thickness shall be as per IEC 60502 or BS 5467 rated for 90° C

^{Rate voltage(U0/U)}	^{NYY: 0.6/1kv N2XY N2XBY N2XFY/RY: 0.6/1kv, 6/10kv, 8.7/15kv, 12/20kv, 26/35kv}
^{Long-term operating temperature of cable conductor}	^{NYY: 70°c N2XY N2XBY N2XFY/RY: 90°c}
^{Laying temperature is not less than}	^-0°c
^{Permission bending radius}	^{NYY: no less than 10 times of cable’s outer diameter N2XY N2XBY N2XFY/RY: single core: no less than 20 times of cables outer diameter three cores: no less than 15 times of cables outer diameter}
^{Number of cores}	^{NYY: single core; 2 cores; 3 cores; 4 cores; 5 cores; 3+1 cores; 3+2 cores; 4+1 cores; N2XY: single core; 3 cores; N2XBY: 3 cores; 4 cores; N2XFY/RY: 3+1 cores; 4 cores;}

Model Specifications

_{NYM Some power cable models and usage scenarios}

_{Wire gauge}	^{Number of cores x conductor}	^{Nominal insulation}	^{Nominal sheath}	^{Nominal outer diameter}	^{Nominal copper weight}	^{Nominal cable weight}
_{Wire gauge}	^{cross-sectional area mm}	^thickness ^mm	^thickness ^mm	^mm	^kg/km	^kg/km
16(solid)	1X1.5	0.6	1.4	5.4	14.4	40
16(solid)	2 X1.5	0.6	1.4	8.7	29	170
16(solid)	3 X1.5	0.6	1.4	9.1	43	135
16(solid)	4 X1.5	0.6	1.4	9.8	58	160
16(solid)	5 X1.5	0.6	1.4	10.3	72	190
16(solid)	7 X1.5	0.6	1.4	11.5	101	235
16(solid)	10 X1.5	0.6	1.4	13.8	144	330
16(solid)	12 X1.5	0.6	1.4	14.4	173	405
14(solid)	1 X2.5	0.7	1.4	6	24	70
14(solid)	3 X2.5	0.7	1.4	10.4	72	190
14(solid)	4 X2.5	0.7	1.4	11.3	96	230
14(solid)	5 X2.5	0.7	1.4	12	120	270
14(solid)	7 X2.5	0.7	1.6	13.2	168	342
12(solid)	1X4	0.8	1.6	6.6	38	80
12(solid)	3 X4	0.8	1.6	12	115	258
12(solid)	4 X4	0.8	1.6	13	154	330
12(solid)	5 X4	0.8	1.6	14.5	192	410
10(solid)	1X6	0.8	1.6	7.2	58	105
10(solid)	3 X6	0.8	1.6	13	173	320
10(solid)	4 X6	0.8	1.6	15.1	230	460
10(solid)	5 X6	0.8	1.6	16.1	288	540
8(solid)	1X10	1	1.6	8.4	96	155
8(solid)	4 X10	1	1.6	17.6	384	680
8(solid)	5 X10	1	1.6	19.2	480	850
6(7/14)	1X16	1.2	1.8	9.9	154	230
6(7/14)	4 X16	1.2	1.8	21.3	614	1048
6(7/14)	5 X16	1.2	1.8	23.4	768	1280
4(7/12)	1×25	1.4	2	12	240	325
4(7/12)	4X25	1.4	2	25.8	960	1649
4(7/12)	5 X25	1.4	2	28.7	1200	1970
2(7/10)	4X35	1.4	2	28.5	1344	2000
