0.6/1kv Nh-Yjv22 N2xby 4 Cores Cu/Mica/XLPE/Dsta/PVC Power Cable

0.6/1kv Nh-Yjv22 N2xby 4 Cores Cu/Mica/XLPE/Dsta/PVC Power Cable image

Get Latest Price Request a quote

Product Details

Model NO.

n2xby cable

Current

DC Cable

Insulation Material

XLPE

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Bare Copper Wire

Certification

ISO, CCC, SGS

Model

N2xby Cable

Brand

Hongda

Rated Voltage

0.6/1kv, 600/1000V, 1.1kv

Transport Package

500m or 1000m Per Drum

Specification

1.5-300 mm2

Trademark

Hongda or OEM

Origin

China

HS Code

8544492100

Production Capacity

4000 Km / Year

Product Description

0.6/1kv NH-YJV22 N2XBY 4 cores Cu/Mica/XLPE/DSTA/PVC power cable

N2XBY 4 x (1.5-300) mm² 0.6/1 kV

Cu / Mica / XLPE / DSTA / PVC

(Copper Conductor, Mica Tape, XLPE Insulated, Double Galvanized Steel Tape Armor, PVC Sheathed)

Standard Specification : IEC 60502-1 and IEC 60331

Application

For wiring of fire resistant safety circuits, such as fire alarm system, emergency lighting and power, public address and emergency voice communication systems in highrise building, control and instrumentation services in industrial, commercial and residential complexes.

Special Features on Request :

• Oil Resistance

• UV Resistance

• Flame Retardant Cat. A, B, C

• Flame Retardant Non Category

• Anti Termite

• Anti Rodent

• Low Smoke Zero Halogen

Note :
Conductor Shape
1.5 – 10 sqmm supplied in solid (re) or non compacted circular stranded (rm) conductor shape
16 sqmm supplied in non compacted circular stranded (rm) conductor shape
25 – 300 sqmm supplied in compacted circular stranded (cm) conductor shape

Standard Packing
1.5 – 50 sqmm supplied in wooden drum @ 1000 m
70 – 300 sqmm will be suplied in wooden drum on available length
Length Tolerance per drum ± 2%

Construction Data

Nom. Cross Section Area	Overall Diameter	Cable Weight
Nom. Cross Section Area	approx.	approx.
mm²	mm	kg/km
1.5	17.6	423
2.5	18.7	499
4	20.0	603
6	22.0	734
10	24.5	970
16	25.5	1,206
25	29.5	1,689
35	32.5	2,164
50	37.0	3,115
70	42.5	4,163
95	46.5	5,334
120	51.5	6,547
150	57.0	7,897
185	62.5	9,698
240	69.5	12,255
300	75.5	14,895

Electrical Data

Conductor			Inductance	Current – Carrying Capacity at 30° C *		Short circuit current at 1 sec
Nom. Cross Section Area	DC Resistance at 20°C	AC Resistance at 90°C		Current – Carrying Capacity at 30° C *
Nom. Cross Section Area	DC Resistance at 20°C	AC Resistance at 90°C		in air	in ground
(mm²)	Max. (Ω/km)	Max. (Ω/km)	(mH/km)	Max. (A)	Max. (A)	Max. (kA)
1.5	12.1	15.429	0.315	27	32	0.21
2.5	7.41	9.449	0.293	36	42	0.36
4	4.61	5.878	0.275	48	55	0.57
6	3.08	3.927	0.263	60	68	0.86
10	1.83	2.334	0.248	83	91	1.43
16	1.15	1.467	0.238	110	118	2.29
25	0.727	0.927	0.240	148	152	3.58
35	0.524	0.669	0.233	183	183	5.01
50	0.387	0.494	0.232	214	210	7.15
70	0.268	0.343	0.229	269	256	10.01
95	0.193	0.247	0.224	334	309	13.59
120	0.153	0.197	0.223	386	350	17.16
150	0.124	0.160	0.224	449	395	21.45
185	0.0991	0.129	0.225	512	444	26.46
240	0.0754	0.099	0.223	604	513	34.32
300	0.0601	0.081	0.221	692	577	42.90

*Further information about rating factor for certain cable arrangement can be found on supplementary technical information
