Product Details

Model NO.

R2V

Current

AC Cable

Insulation Material

PVC

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Red Copper Wire

Certification

ISO, CCC

Model

Cu XLPE PVC

Brand

OEM

Product Name

Copper XLPE Insulation PVC Sheath 2 Core Wire

Conductor

99.99% Copper

Packaging

Wooden Drum

Transport Package

Wooden Drum

Specification

3C 2.5mm2

Trademark

OEM

Origin

China(Mainland)

HS Code

8544492100

Production Capacity

15 Kilometer/ Day

Product Description

0.6/1 kV copper XLPE Insulation PVC Sheath 2 core 2.5mm wire cable R2V

1.Brief Introduction :

cable is Cu conductor PVC insulated PVC sheath Electric power cable for laying buildings,inducts , kin tunnels,direct in ground and under water,.

For laying indoors , in tunnels, in ducts. Able to bear extermal mechanical force but not large pulling forces. Single core cables are impermissible to be laid in magnetic ducts.

2.Operating characteristics:

Rated power-frequency voltage u0/u:0.6/1 KV

Max permissible continuous operating temperature of conductor 70

Max short-circuit temperature of the conductor shall not exceed (Max 5 seconds duration): cross-section of conductor 300 mm²

The anbient temperature under installations should not be below 0

The bending radius of single core cable should not be less than 20 times of the cable diameter ,the bending radius of multi-core cable should not be less than 15 times of the cable diameter

Cross-section	Insulation Thickness		Sheathb Thickness	Overall Diameter	Weight		The conductor resistant at 20°C
					cu	al	cu		al
mm2	mm	mm	mm	mm	Kg/km	Kg/km	Ω/km		Ω/km
3×4+1×2.5	1.0	0.8	1.8	14.3	254	221	4.61	7.41	7.41	12.1
3×6+1×4	1.0	1.0	1.8	15.8	400	671	3.08	4.61	4.61	7.41
3×10+1×6	1.0	1.0	1.8	18.5	595	334	1.83	3.08	3.02	4.61
3×16+1×10	1.0	1.0	1.8	21.1	853	467	1.15	1.83	1.91	3.02
3×25+1×16	1.2	1.0	1.8	24.9	1267	671	0.727	1.15	1.20	1.91
3×35+1×16	1.2	1.0	1.8	27.1	1591	806	0.524	1.15	1.868	1.91
3×50+1×25	1.4	1.2	1.9	30.4	2124	996	0.387	0.727	0.641	1.20
3×70+1×35	1.4	1.2	2.0	33.9	2851	1271	0.268	0.524	0.443	0.868
3×95+1×50	1.6	1.4	2.2	39.5	3844	1684	0.193	0.387	0.320	0.641
3×120+1×70	1.6	1.4	2.3	44.0	4833	2060	0.153	0.268	0.253	0.443
3×150+1×70	1.8	1.4	2.4	48.5	5841	2488	0.124	0.268	0.206	0.320
3×185+1×95	2.0	1.6	2.6	53.3	7246	3056	0.0991	0.193	0.164	0.253
3×240+1×120	2.2	1.6	2.8	55.0	9216	3801	0.0754	0.153	0.125	0.206
3×300+1×150	2.4	1.6	3.1	59.8	11388	4769	0.0601	0.124	0.100	0.164
3×400+1×240	2.6	1.6	3.3	66.0	14562	5968	0.0470	0.0754	0.0778	0.125

Packing shipping:

Certification:
