0.6/1 Kv Aluminum XLPE Power Cable 4X35mm 4X50mm 4X95mm 4X120mm Cable Axmk
0.6/1 Kv Aluminum XLPE Power Cable 4X35mm 4X50mm 4X95mm 4X120mm Cable Axmk image
Get Latest Price Request a quote
You May Like
Product Details
Product Description
AXMK Cable Application
AXMK Cable Standard
Insulation: XLPE compound
Bedding: Extruded elastomere or plastomere
compound or plastic tape
Sheath: PVC compound, UV resistant, black or by customer request
Test Voltage:4kV/50Hz
Minimum Laying temperature: -15ºC
Short Circuit Temperature:250°C
Minimum Bending Radius
10 x overall diameter
CONSTRUCTION CHARACTERISTICS
| NOMINAL CROSS-SEC- TION | CONDUCTOR CONSTRUC- TION | MAX. RESIS- TANCE AT 20°c |
NOM. THICKNESS OF INSULATION | CURRENT CAPACITY IN AIR | CURRENT CAPACITY IN EARTH | OUTER DIAM. (APPROX.) | METAL WEIGHT | CABLEWEIGHT (APPROX.) | |
| mm2 | Ω/km | A | A | mm | kg/km | kg/km | |||
| 1×16 | RE | 1,910 | 0,7 | – | – | 9,5 | 46 | 122 | |
| 1×25 | RE | 1,200 | 0,9 | 106 | 114 | 11,9 | 73 | 175 | |
| 1×35 | RM | 0,868 | 0,9 | 130 | 136 | 13 | 102 | 206 | |
| 1×50 | RM | 0,641 | 1 | 161 | 162 | 14,9 | 145 | 267 | |
| 1×70 | RM | 0,443 | 1,1 | 204 | 199 | 17 | 203 | 358 | |
| 1×95 | RM | 0,320 | 1,1 | 252 | 238 | 18,9 | 276 | 451 | |
| 1×120 | RM | 0,253 | 1,2 | 295 | 272 | 20,7 | 348 | 546 | |
| 1×150 | RM | 0,206 | 1,4 | 339 | 305 | 22,7 | 435 | 655 | |
| 1×185 | RM | 0,164 | 1,6 | 395 | 347 | 25,1 | 537 | 800 | |
| 1×240 | RM | 0,125 | 1,7 | 472 | 404 | 27,6 | 696 | 987 | |
| 1×300 | RM | 0,100 | 1,8 | 547 | 457 | 31,9 | 870 | 1324 | |
| 1×400 | RM | 0,0778 | 2 | 643 | 525 | 34,9 | 1160 | 1640 | |
| 1×500 | RM | 0,0605 | 2,2 | 754 | 601 | 39,3 | 1450 | 2030 | |
| 1×630 | RM | 0,0469 | 2,4 | 882 | 687 | 44,1 | 1827 | 2400 | |
| 1×800 | RM | 0,0367 | 2,6 | 1080 | 1300 | 49 | 2320 | 2974 | |
| 1×1000 | RM | 0,0291 | 2,8 | 1145 | 1490 | 54 | 2900 | 3315 | |
| 4×16 | RE | 1,910 | 0,7 | 78 | – | 18,3 | 185 | 596 | |
| 4×25 | SM | 1,200 | 0,9 | 100 | – | 21,1 | 290 | 509 | |
| 4×35 | SM | 0,868 | 0,9 | 111 | 134 | 23,4 | 406 | 653 | |
| 4×50 | SM | 0,641 | 1 | 136 | 165 | 26,4 | 580 | 832 | |
| 4×70 | SM | 0,443 | 1,1 | 176 | 214 | 30,4 | 812 | 1118 | |
| 4×95 | SM | 0,320 | 1,1 | 215 | 263 | 34,1 | 1102 | 1465 | |
| 4×120 | SM | 0,253 | 1,2 | 251 | 308 | 38,1 | 1392 | 1837 | |
| 4×150 | SM | 0,206 | 1,4 | 290 | 357 | 42,1 | 1740 | 2250 | |
| 4×185 | SM | 0,164 | 1,6 | 334 | 411 | 46,6 | 2146 | 2807 | |
| 4×240 | SM | 0,125 | 1,7 | 397 | 490 | 52,2 | 2784 | 3603 | |
| 4×300 | SM | 0,100 | 1,8 | 460 | 569 | 55,9 | 3480 | 4223 | |
| 5×10 | RE | 3,08 | 0,7 | – | – | 17,8 | 145 | 422 | |
| 5×16 | RE | 1,91 | 0,7 | 78 | – | 20 | 232 | 544 | |
| 5×25 | SM | 1,200 | 0,9 | 102 | 112 | 22,9 | 363 | 606 | |
| 5×35 | SM | 0,868 | 0,9 | 111 | 135 | 25,7 | 507,8 | 807 | |
| 5×50 | SM | 0,641 | 1 | 136 | 165 | 30,1 | 725 | 1032 | |
| 5×70 | SM | 0,443 | 1,1 | 176 | 214 | 35,1 | 1015 | 1404 | |
| 5×95 | SM | 0,320 | 1,1 | 215 | 263 | 38,1 | 1380 | 1800 | |
| 5×120 | SM | 0,253 | 1,2 | 273 | 268 | 40,3 | 1740 | 2320 | |
| 5×150 | SM | 0,206 | 1,4 | 290 | 357 | 47,4 | 2175 | 2900 | |
| 5×185 | SM | 0,164 | 1,6 | 334 | 411 | 52,7 | 2682,5 | 3352,5 | |
| 5×240 | SM | 0,125 | 1,7 | 397 | 490 | 59,4 | 3480 | 4350 | |
