XLPE Mv-90 Power Cable Armored Cable Electrical Cable Price

XLPE Mv-90 Power Cable Armored Cable Electrical Cable Price image

Get Latest Price Request a quote

Product Details

Model NO.

Mv-90 Power Cable

Current

AC Cable

Insulation Material

XLPE

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Bare Copper Wire

Certification

ISO, CCC, CE, RoHS

Model

Yjv32

Brand

Rneda

Certificate

UL Ce TUV BV Kema SABS Psb

Size

1.5-800mm

Core

Single 2 3 4 3+1 4+1 3+2

Conductor

Copper or Aluminum

Usage

Underground

Armour

Steel Wire

Type Conductor

Stranded or Solid

Transport Package

Wooden & Steel Drum

Specification

IEC DIN ASTM VDE BS

Trademark

RNEDA

Origin

China

HS Code

8544492100

Production Capacity

1000km Per Month

Product Description

XLPE Mv-90 Power Cable Armored Cable Electrical Cable Price

TOP TEN CABLE MANUFACTURER IN CHINA

LARGEST CABLE MANUFACTUER IN NORTH CHINA

ANNUAL EXPORT VOLUME EXCEED 200MILLION USD

WITH UL,TUV,KEMA,CE,BV,PSB,SABS,LLOYD’S,GL,NK,KR,ABS PRODUCTS CERTIFICATIONS

WITH TUV TYPE TESTING REPORT

WIDE PRODUCTS RANGE

ISO9001,ISO18001,OHSAS18001 SYSTEM CERTIFICATIONS

CNAS APPROVAL LABROTARY

Product Description

Applications

Predominantly used for primary underground distribution in conduit systems; suitable for use in wet or dry locations, direct burial, underground duct, and where exposed to sunlight.

Specifications
Primary UD TRXLP Cable meets or exceeds the following ASTM specifications:
• B3 Soft Annealed Copper Wire
• B8 Concentric-Lay-Stranded Copper Conductors, Hard, Medium-Hard or Soft
• B230 Aluminum, 1350-H19 Wire for Electrical Purposes
• B231 Aluminum 1350 Conductors, Concentric-Lay-Stranded
• B609 Aluminum 1350 Round Wire, Annealed and Intermediate Tempers, for Electrical Purposes

Construction

The cable is composed of a solid or moisture blocked reverse lay, compressed stranded soft drawn copper, or a solid or moisture blocked reverse lay or unilay compressed stranded 1350-H16/26 aluminum phase conductor, covered by a semi-conducting cross-linked polyethylene strand shield, a tree-retardant cross-linked polyethylene primary insulation, and a semi-conducting cross-linked polyethylene insulation shield. Conductors are available with 100% insulation levels. A concentric neutral of bare copper wires and a sunlight resistant, -40°C rated, insulating linear low density polyethylene jacket are applied over the insulation shield. The cable is identified by surface print on the jacket and with the lightning bolt symbol for supply cables indented in the jacket. Red extruded stripes available upon request.

Data Sheet

Phase Conductor		Neutral		Thickness Per Cond. (mils)				Diameter (mils)			Weight 1000 feet (lbs.)
Size (AWG or kcmil)	Stranding	No. of Wires	Size (AWG)	Nominal Insul.	Insul. Shield min. Point	Approx. Jkt.	Bare Phase Cond.	Over Insul.	Over Insul. Shield	Comp. Cable	Comp. Cable
ALUMINUM CONDUCTOR – 0.345 INSULATION – 100% INSULATION LEVEL ” FULL COPPER WIRE NEUTRAL
1*1/0	19	16	14	345	40	55	335	1066	1176	1414	977
1*2/0	19	13	12	345	40	55	376	1107	1217	1488	1123
1*3/0	19	16	12	345	40	55	423	1153	1263	1534	1249
1*4/0	19	13	10	345	40	80	474	1212	1322	1686	1537
1*250	37	15	10	345	40	80	523	1261	1371	1735	1678
1*300	37	18	10	345	40	80	572	1310	1420	1784	1858
1*350	37	21	10	345	40	80	617	1355	1465	1829	2034
1*400	37	19	9	345	40	80	661	1399	1509	1898	2243
1*450	37	21	9	345	40	80	701	1439	1549	1938	2400
1*500	37	19	8	345	40	80	738	1476	1586	2003	2626
1*550	61	21	8	345	55	80	783	1527	1657	2074	2859
1*600	61	23	8	345	55	80	817	1561	1691	2108	3033
1*650	61	25	8	345	55	80	850	1594	1724	2141	3205
1*700	61	26	8	345	55	80	883	1627	1757	2174	3332
1*750	61	28	8	345	55	80	914	1658	1788	2205	3502
1*800	61	30	8	345	55	80	943	1687	1817	2234	3671
ALUMINUM CONDUCTOR – 0.345 INSULATION – 100% INSULATION LEVEL ” 1/3 COPPER WIRE NEUTRAL
1*1/0	19	6	14	345	40	55	335	1066	1176	1414	859
1*2/0	19	7	14	345	40	55	376	1107	1217	1455	928
1*3/0	19	9	14	345	40	55	423	1153	1263	1501	1021
1*4/0	19	11	14	345	40	55	474	1212	1322	1561	1136
1*250	37	13	14	345	40	55	523	1261	1371	1609	1237
1*300	37	15	14	345	40	80	572	1310	1420	1708	1405
1*350	37	18	14	345	40	80	617	1355	1465	1754	1525
1*400	37	13	12	345	40	80	661	1399	1509	1831	1682
1*450	37	14	12	345	40	80	701	1439	1549	1870	1780
1*500	37	16	12	345	40	80	738	1476	1586	1907	1896
1*550	61	18	12	345	55	80	783	1527	1657	1979	2067
1*600	61	19	12	345	55	80	817	1561	1691	2013	2163
1*650	61	13	10	345	55	80	850	1594	1724	2088	2333
1*700	61	14	10	345	55	80	883	1627	1757	2121	2440
1*750	61	15	10	345	55	80	914	1658	1788	2152	2545
1*800	61	16	10	345	55	80	943	1687	1817	2181	2648
1*900	61	18	10	345	55	80	1001	1745	1875	2239	2854
1*1000	61	20	10	345	55	80	1055	1800	1930	2293	3058
1*1250	61	20	9	345	55	80	1180	1924	2054	2443	3606

Phase Conductor		Neutral		Thickness Per Cond. (mils)				Diameter (mils)			Weight 1000 feet (lbs.)
Size (AWG or kcmil)	Stranding	No. of Wires	Size (AWG)	Nominal Insul.	Insul. Shield min. Point	Approx. Jkt.	Bare Phase Cond.	Over Insul.	Over Insul. Shield	Comp. Cable	Comp. Cable
ALUMINUM CONDUCTOR – 0.345 INSULATION – 100% INSULATION LEVEL ” 1/6 COPPER WIRE NEUTRAL
1*1/0	19	5	16	345	40	55	335	1066	1176	1387	799
1*2/0	19	6	16	345	40	55	376	1107	1217	1428	863
1*3/0	19	7	16	345	40	55	423	1153	1263	1475	938
1*4/0	19	9	16	345	40	55	474	1212	1322	1534	1044
1*250	37	10	16	345	40	55	523	1261	1371	1583	1128
1*300	37	8	14	345	40	80	572	1310	1420	1708	1323
1*350	37	9	14	345	40	80	617	1355	1465	1754	1418
1*400	37	10	14	345	40	80	661	1399	1509	1797	1515
1*450	37	12	14	345	40	80	701	1439	1549	1837	1617
1*500	37	8	12	345	40	80	738	1476	1586	1907	1746
1*550	61	9	12	345	55	80	783	1527	1657	1979	1899
1*600	61	10	12	345	55	80	817	1561	1691	2013	1995
1*650	61	11	12	345	55	80	850	1594	1724	2046	2089
1*700	61	11	12	345	55	80	883	1627	1757	2079	2166
1*750	61	12	12	345	55	80	914	1658	1788	2109	2258
1*800	61	13	12	345	55	80	943	1687	1817	2139	2349
1*900	61	14	12	345	55	80	1001	1745	1875	2196	2513
1*1000	61	16	12	345	55	80	1055	1800	1930	2251	2693
1*1250	61	20	12	345	55	80	1180	1924	2054	2376	3112

Packaging & Shipping

Company Information

Hebei Huatong Wires and Cables Group Co., Ltd was established in 1993, covering an area of 230, 000 square meters. We own more than 420 sets manufacturing equipment and 250 sets of testing equipment or apparatus. Our annual production capacity is 5 billion Yuan.We have 1200 employers, among which 150 are technicians. Based on the scientific management, now we are a comprehensive, large-scale enterprises in wire and cable industry.Voltage up to 35KV, including X L P E power cables,PVC power cables, mining cables, rubber cables for general purpose, Submersible oil pump cables, solar cables, shipboard cables,lead sheath cables, aerial cables, control and instrument cables, special cables etc.Products are exported to USA, Australia, Singapore, Europe, South America, Middle East, Asia, Africa. CNAS accredited national level laboratory.

UL Certificates

We are one of China top rank cable&wire manufacturer.Our products meet standards of GB, IEC DIN ASTM, JIS, NF, AS/NZS CSA GOST and so on. We also have obtained ISO9001,ISO14001,OHSAS18001, UL,CE,

KEMA, TUV, SABS,PBS,Bureau Veritas, Lloyd,GL,NK,KR certifications.

We have obtained UL certifications for TC cable, DLO cable,RHH/RHW/RHW-2,XHHW/XHHW-2/SIS, THHN,SER/SEU/USE, MV-90/MV-105,MC cable,AC cable,TECK 90,SOOW,Welding cable,Mining cable,type DG,PV cable,Shipboard cable and so on.

Laboratory

CNAS accredited national level laboratory.

Our Services

1.25 years production experience and 16 years export experience .
2.Products certification :UL,CE,BV,TUV,KEMA,PSB,SABS,ABS,NK,LR,KR,GL etc
3. OEM service available based on official & legal authorization.
4.Strict quality control system.
5.Rapid delivery and feedback Faster lead time than our competitors.
6.Excellent quality with reasonable price.
7.Strong technical support (technical data, drawing, etc.)
8.Professional teamwork service for you actively.
9.Stock available, Free sample is available.

FAQ

(1).When can I get the price?
We usually quote within 6 hours after we get your inquiry. If you are very urgent to get the price,please call us ortell us in your e-mail so that we will regard your inquiry priority.

(2).How can I get a sample to check your quality?
After price confirmation, you can require for samples to check our quality. Sample is free, but the freight charge should be paid.

(3).How long can I expect to get the sample?
After you pay the freight charge and send us confirmed files, the samples will be ready for delivery in 3-7 days. The samples will be sent to you via express and arrive in 3~5 days. You can use your own express account or prepay us if you do not have an account.

(4).What about the lead time for mass production?
Honestly, it depends on the order quantity and the season you place the order.The best record we keep is delivering 10 kilometers cable within a week. Generally speaking, we suggest that you start inquiry two months before the date you would like to get the products at your country.

We are China XLPE Mv-90 Power Cable Armored Cable Electrical Cable Price manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
