XLPE Insulation Copper Use-2 / Rhh / Rhw-2 Building Wire

XLPE Insulation Copper Use-2 / Rhh / Rhw-2 Building Wire image

Get Latest Price Request a quote

Product Details

Model NO.

use-2

Application

Heating, Building

Conductor Material

Aluminum 8000

Sheath Material

None

Insulation Material

XLPE

Material Shape

Round Wire

Range of Application

Conduit or Recognized Raceways for Services

Certification

ISO9001, CE, CCC, RoHS, VDE

Brand

Huatong

Rated Voltage

Low Voltage 600V

Standard

UL44

Rated Temperature

Dry or Wet 90c

Performance

Sun Res

Transport Package

Coils and Drums

Specification

14awg-1000mcm

Trademark

Renda

Origin

China

HS Code

8544492100

Production Capacity

200000m/Month

Product Description

Type RHH, RHW, RHW-2,USE,USE-2

Application:

Type RHH, RHW, RHW-2,USE,USE-2 cables are used for lighting, power, and general wiring applications.These cables are suitable for installation in raceway, duct, direct burial, and aerial installations in accordance with National Electric Code and other general-purpose wiring applications.

Structure:

1. Conductor: Soft plain copper, conforms to ASTM B3, B8.

Compact stranded AA-8000 series aluminum alloy,conforms to ASTM-B-800,B-801

2. Insulation: Cross-linked polyethylene(XLPE)insulation with property of heat, moistrure and abrasion resistance and flame retardant

Standard:

UL 44 for RHH, RHW, RHW-2

UL 854 for USE USE-2

UL File No.:

E466693

Voltage:

600V and 2000V

Working temperature:

Temperature in dry locations not exceed 90ºC for Type RHH

Temperature in wet and dry locations not exceed 75ºC for Type RHW-2,USE-2

Temperature in wet and dry locations not exceed 90ºC for Type RHW-2,USE-2

Performance:

High heat;

Sunlight;

Moisture;

Printing:

HT CABLES (UL) E466693 Type RHH/ RHW/ RHW-2/USE/USE-2 *AWG 600V 90C DRY OR WET SUN RES 2023 ****FT

Technical data 600V—CU:

Conductor		Insulation Thickness (mils)	Nominal O.D. (mils)	Net Wt. Per 1000′ (lbs.)	Allowable Ampacities+
Size (AWG or kcmil)	No. of strands				Allowable Ampacities+
Size (AWG or kcmil)	No. of strands				60°C	75°C	90°C
14	7	45	160	20	15	15	15
12	7	45	177	29	20	20	20
10	7	45	201	42	30	30	30
8	7	60	256	68	40	50	55
6	7	60	294	101	55	65	75
4	7	60	341	154	70	85	95
2	7	60	397	235	95	115	130
1	19	80	484	309	110	130	145
1/0	19	80	520	379	125	150	170
2/0	19	80	557	472	145	175	195
3/0	19	80	614	583	165	200	225
4/0	19	80	673	729	195	230	260
250	37	95	748	863	215	255	290
300	37	95	804	1029	240	285	320
350	37	95	854	1191	260	310	350

UL Certificate for XHHW,SER,SEU,MC Cable

We are China XLPE Insulation Copper Use-2 / Rhh / Rhw-2 Building Wire manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
