XLPE Insulation Aluminum Conductor Copper Tape Screen 12/20kv Medium Voltage Power Cable

XLPE Insulation Aluminum Conductor Copper Tape Screen 12/20kv Medium Voltage Power Cable image

Get Latest Price Request a quote

Product Details

Model NO.

YJLV YJL V22 N2XSY YJL V32

Current

DC & AC

Insulation Material

XLPE

Material Shape

Round Wire

Wire Core Material

Bare Copper Wire

Certification

ISO, CCC, CE, RoHS

Color

White/Black

MOQ

500m

Conductor

Copper

Insulation

XLPE

Sheath

Transport Package

Wooden Steel Drum

Specification

1.1*1.1*0.98m

Trademark

Shanghai Shenghua Cable Group

Origin

Shanghai, China

HS Code

8544492100

Production Capacity

100000

Packaging & Delivery

Package Size

100.00cm * 10.00cm * 10.00cm

Package Gross Weight

15.000kg

Product Description

XLPE Insulation Aluminum Conductor Copper Tape Screen 12/20kv Medium Voltage Power Cable

Medium Voltage 6/10kv 8.7/15kv 12/20KV Aluminium Armoured XLPE Power Cable

Application
They are suitable for installation mostly in power supply stations, indoors and in cable ducts, outdoors, underground and in water as well as for installation on cable trays for industries, switchboards and power stations.
Conductor: Plain annealed copper or aluminium wire. Copper conductors shall be stranded (class 2) and aluminium conductors shall be either solid or stranded (class 2).
Conductor Screen: Extruded layer of semi-conducting cross-linkable compound.
Insulation: cross-linked polyethylene compound XLPE or EPR.
Insulaton Screen: Extruded layer of semi-conducting cross-linkable compound is applied over the insulation.
Metallic Layer: copper tapes or a concentric layer of copper wires or a combination of tapes and wires.
Separation Sheath (for armoured cable): PVC, PE or LSZH.
Armour (for armoured cable): round aluminium wire.
Over Sheath: PVC or MDPE. LSZH can be offered as an option.

Cable Parameters(Single Core)

Nom. Cross-Section Area		Armoured Cables
	Nom. Insulation Thickness	Copper Tape Screen Area	Nom. Bedding Thickness	Nom. Armour Wire Diameter	Nom. Sheath Thickness	Approx. Overall Diameter	Approx. Weight
							Approx. Weight
							CU	AL
mm^2	mm	mm^2	mm	mm	mm	mm	kg/km	kg/km
50	8	6.7	1.2	2	2.2	41	2300	1980
70	8	7.1	1.2	2	2.2	42.6	2560	2120
95	8	7.5	1.2	2	2.3	44.4	2890	2290
120	8	7.9	1.2	2	2.3	45.8	3200	2430
150	8	8.2	1.3	2.5	2.4	48.9	3760	2830
185	8	8.6	1.3	2.5	2.5	50.6	4180	3010
240	8	9.2	1.3	2.5	2.5	53.1	4830	3270
300	8	9.7	1.4	2.5	2.6	55.5	5540	3630
400	8	10.3	1.4	2.5	2.7	59.4	6680	4130
500	8	11	1.5	2.5	2.8	62.2	7790	4690
630	8	11.8	1.5	2.5	2.9	67.4	9290	5220

Description:

AL/XLPE/PVC/AWA/PVC, IEC 60331

IEC 60502, IEC 60227, IEC 60331, IEC 601034, IEC60754 GB/T 12706-91 GB306.1-2001, GB/T18380.3-2001

CE, CCC, KEMA

Constructions

Conductor: Circular stranded copper conductor, conforms to IEC 60228 class 2

Insulation: XLPE/A

Inner Covering: LSOH

Sheath: LSOH , black

Note: Insulation color as per standards or customer requirement

Applications

Used for tall building, Hospital, Theatre, Power station, Metro Tunnel or Petrochemical Industry or other special place required for low smoke , zero halogen clean and safe cable.

Standards

International: IEC 60502, IEC 60227 IEC 60331, IEC 601034

China: GB/T 12706-91 GB306.1-2001, GB/T18380.3-2001

Other standards such as BS,DIN and ICEA upon request

Technical data

Rated voltage: 0.6-KV

Max. Conductor Temp.: normal (90ºC), short circuit no more than 5 s (the highest temperature of conductor shall no more than 250ºC )

Min. Ambient Temp.:The cable shall be pre heated if the ambient temperature is below 0ºC

Min. Bending Radius: single core cable 20(d+D)±5%

Multi-core cable 15(d+D)±5%

Product Name	XLPE Insulation Aluminum Conductor Copper Tape Screen 12/20kv Medium Voltage Power Cable
Model/Standard	CU/XLPE/LSOH, IEC 60331, IEC 60502, IEC 60227, IEC 60331, IEC 601034, IEC 60754, GB/T 12706-91, GB306.1-2001, GB/T18380.3-2001, CE, CCC, KEMA
Conductor Material	Circular stranded copper conductor, conforms to IEC 60228 class 2
Insulation Material	XLPE/A
Inner Covering	PVC
Sheath Material	PVC , black
Insulation Color	As per standards or customer requirement
Rated Voltage	12/20kV
Max. Conductor Temperature	Normal: 90°C; Short circuit (5 seconds): Maximum conductor temperature not exceeding 250°C
Min. Ambient Temperature	Cable should be preheated if ambient temperature is below 0°C
Min. Bending Radius	Single-core cable: 20(d+D)±5%; Multi-core cable: 15(d+D)±5%

We are China XLPE Insulation Aluminum Conductor Copper Tape Screen 12/20kv Medium Voltage Power Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
