Underground Construction 600V Teck 90 Cable Wire

Underground Construction 600V Teck 90 Cable Wire image

Get Latest Price Request a quote

Product Details

Model NO.

teck90

Application

Underground

Conductor Material

Copper or Aluminum

Sheath Material

PVC

Insulation Material

XLPE

Material Shape

Round Wire

Range of Application

Commercial, Industrial

Certification

ISO9001, CE, CCC, RoHS, VDE

Brand

Huatong

Voltage

Low Voltage 600V, 2000V

Armored Material

Aluminum/Steel Interlock

Number of Cores

Mutil Cores

Temperature

-40-90

Transport Package

Coils and Drums

Specification

12AWG to 2000KCMIL

Trademark

HT CABLES

Origin

China

HS Code

8544492100

Production Capacity

200000m/Month

Product Description

XLPE Insulation PVC Sheathed AIA Armoured Cable TECK90

Multi Conductor, 14AWG -1000 Kcmil Copper, FT4 – Flame Retardancy Rating, XLPE Insulation, Aluminum Interlocked Armour, Sunlight Resistant, Direct Buried, -40°C – 90°C, Rated HL, AG14

Teck 90 is for use in power, control and lighting circuits at industrial and chemical plants, pulp and paper mills, steel mills, mines, power generating facilities, food processing plants and commercial centers. It is suitable for installation in wet or dry locations in troughs, trays and in direct burial applications. Teck 90 is for applications up to 600 volts and temperatures from -40°C to +90°C.

UL No.: ZKST.E466697

•Use and installation

For concealed wiring in dry or wet locations For exposed wiring in dry or wet locations

For exposed and wiring in dry, locations where subjected to corrosive action if suitable for corrosive

conditions encountered

For exposed wiring where subjected to the weather

For use in ventilated, Non-ventilated and ladder-type cable trays in dry or wet locations

For direct earth burial (with protection as required by inspection authority)

For service entrance above or below ground

•Construction

Conductor:

Class B Stranded copper

Insulation:

Cross-linked Polyethylene (XLPE) Type

RW90

Bonding wire:

Bare or stranded copper

Inner jacket:

Polyvinyl Chloride (PVC), black

Armour:

Aluminum interlocked armor

Our jacket:

Polyvinyl Chloride (PVC), black

Voltage:

1000V

Temperature:

Rated-40°C~90°C

Standard:

CUL1569

CSA Standard C22.2 No. 131, No.38 and

No.2256, RoHS

Armor	Interlocked Aluminum Strip
Inner Conductor	Solid/ Stranded Copper
Conductor Insulation	THHN/ THWN OR XHHW-2
Assembly Covering	Polypropylene Tape
Temperature Rating	≤ 90 (dry); ≤ 75 (wet)
Grounding	Insulated Green Grounding Conductor
Voltage Rating	600V

We are China Underground Construction 600V Teck 90 Cable Wire manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
