UL854 Auminum Ser-AA-8000, XLPE, 600V, Four Conductor Concentric Cable

UL854 Auminum Ser-AA-8000, XLPE, 600V, Four Conductor Concentric Cable image

Get Latest Price Request a quote

Product Details

Model NO.

Type SE Service Entrance Cable

Application

Overhead

Conductor Material

A8000

Sheath Material

UV-XLPE

Insulation Material

XLPE

Material Shape

Round and Flat

Range of Application

Underground Service Entrance/Ud

Certification

ISO9001, CE, CCC, RoHS, VDE

Brand

Rne Da

Market

North America and South America

Transport Package

Exported Standard Package

Specification

2x6+6AWG

Trademark

RNE DA

Origin

Hebei, China (Mainland)

HS Code

8544492100

Production Capacity

10000km Per Month

Packaging & Delivery

Package Size

20.00cm * 20.00cm * 5.00cm

Package Gross Weight

5.000kg

Product Description

UL854 Auminum Ser-AA-8000, XLPE, 600V, Four Conductor Concentric Cable

Product Description

1 Applications:
HUATONG Aluminum Service Entrance Cable Type SE, with rated voltage 600V, is used to transmit power from the junction box to the meter
base and from the meter base to the distribution cabinet. It may be used in all applications where Type SE cable is permitted.Type SE cable
could be used in dry or wet environmet at the working temperature not exceed 90C.

2 Standard:
ASTM-B-800 and B-801
UL Standard 44 for XHHW-2
UL Standard 854 for SER/SRU
RoHS environmental conductive requirement.

3 Product Charactors:
Conductor:AA-8030 aluminum alloy conductors
Insuation:Cross-linked polyethylene(XLPE) Insulation
Jacket: Sunlight resistant,moisture resistant and flame retardant
Temperature Range: Temperature of 90C in wet and dry locations
Environmental: Free of harmful heavy metals in compliance with ROHS
Voltage Rating:600Volt.

4 Specification:
The AA-8000 aluminum alloy conductor is applied in Type SER/SEU cable. Its insulated core is complied to the requirment of Type XHHW-2 in
UL44. Insulation material is cross-linked polyethylene(XLPE) with characteristics of abrasion resistance,moisture proof and heat resisting.
Meanwhile the insulation has the flame retardant property,which can meet FT2 level combustion test requirment. The outside of cable core
should be wrapped a fibrage tape,both of the insulation wire core and outer sheathed can meet the 720h sunlight resistance requirment.

Technical data

Conductor Size (AWG, Kcmil)									Phase Conductor	Neutral Conductor	Nominal Thickness	Sheath Thickness	Dia.	Weight(kg/km)
Conductor Size (AWG, Kcmil)									Dia.	Dia.	mm	Sheath Thickness	Dia.	Weight(kg/km)
2	×	8	AWG	+	1	×	8	AWG	3.34	3.34	1.14	0.76	12.3	158
2	×	6	AWG	+	1	×	6	AWG	4.22	4.22	1.14	0.76	14.2	214
2	×	4	AWG	+	1	×	4	AWG	5.32	5.3	1.14	0.76	16.6	299
2	×	4	AWG	+	1	×	6	AWG	5.32	4.22	1.14	0.76	15.8	274
2	×	2	AWG	+	1	×	4	AWG	6.70	5.32	1.14	0.76	18.6	387
2	×	2	AWG	+	1	×	2	AWG	6.70	6.70	1.14	0.76	19.6	426
2	×	1	AWG	+	1	×	3	AWG	7.53	5.98	1.40	0.79	21.1	489
2	×	1	AWG	+	1	×	1	AWG	7.53	7.53	1.40	0.81	22.2	540
2	×	1/0	AWG	+	1	×	2	AWG	8.46	6.70	1.40	0.83	23.0	590
2	×	1/0	AWG	+	1	×	1/0	AWG	8.46	8.46	1.40	0.85	24.3	654
2	×	2/0	AWG	+	1	×	1	AWG	9.50	7.53	1.40	0.87	25.2	715
2	×	2/0	AWG	+	1	×	2/0	AWG	9.50	9.50	1.40	0.90	26.6	795
2	×	3/0	AWG	+	1	×	1/0	AWG	10.66	8.46	1.40	0.92	27.6	871
2	×	3/0	AWG	+	1	×	3/0	AWG	10.66	10.66	1.40	0.95	29.3	971
2	×	4/0	AWG	+	1	×	2/0	AWG	11.98	9.50	1.40	0.97	30.4	1065
2	×	4/0	AWG	+	1	×	4/0	AWG	11.98	11.98	1.40	1.00	32.2	1189
2	×	250	MCM	+	1	×	3/0	AWG	13.02	10.66	1.65	1.03	33.5	1288
2	×	250	MCM	+	1	×	250	MCM	13.02	13.02	1.65	1.06	35.3	1419

3	×	8	AWG	+	1	×	8	AWG	3.34	3.34	1.14	0.76	14.0	207
3	×	6	AWG	+	1	×	6	AWG	4.22	4.22	1.14	0.76	16.2	282
3	×	4	AWG	+	1	×	6	AWG	5.32	4.22	1.14	0.76	18.2	369
3	×	4	AWG	+	1	×	4	AWG	5.32	5.32	1.14	0.76	18.8	394
3	×	2	AWG	+	1	×	4	AWG	6.70	5.32	1.14	0.80	21.4	528
3	×	2	AWG	+	1	×	2	AWG	6.70	6.70	1.14	0.81	22.3	568
3	×	1	AWG	+	1	×	3	AWG	7.53	5.98	1.40	0.85	24.4	672
3	×	1	AWG	+	1	×	1	AWG	7.53	7.53	1.40	0.87	25.4	722
3	×	1/0	AWG	+	1	×	2	AWG	8.46	6.70	1.40	0.90	26.6	811
3	×	1/0	AWG	+	1	×	1/0	AWG	8.46	8.46	1.40	0.92	27.7	874
3	×	2/0	AWG	+	1	×	1	AWG	9.50	7.53	1.40	0.94	29.1	983
3	×	2/0	AWG	+	1	×	2/0	AWG	9.50	9.50	1.40	0.97	30.3	1062
3	×	3/0	AWG	+	1	×	1/0	AWG	10.66	8.46	1.40	1.00	31.8	1198
3	×	3/0	AWG	+	1	×	3/0	AWG	10.66	10.66	1.40	1.02	33.2	1296
3	×	4/0	AWG	+	1	×	2/0	AWG	11.98	9.50	1.40	1.06	35.0	1464
3	×	4/0	AWG	+	1	×	4/0	AWG	11.98	11.98	1.40	1.09	36.6	1587
3	×	250	MCM	+	1	×	3/0	AWG	13.02	10.66	1.65	1.13	38.6	1767
3	×	250	MCM	+	1	×	250	MCM	13.02	13.02	1.65	1.16	40.1	1897

4	×	8	AWG	+	1	×	8	AWG	3.34	3.34	1.14	0.76	15.8	256
4	×	6	AWG	+	1	×	6	AWG	4.22	4.22	1.14	0.76	18.1	349
4	×	4	AWG	+	1	×	6	AWG	5.32	4.22	1.14	0.78	20.6	467
4	×	4	AWG	+	1	×	4	AWG	5.32	5.32	1.14	0.79	21.2	493
4	×	2	AWG	+	1	×	4	AWG	6.70	5.32	1.14	0.85	24.3	672
4	×	2	AWG	+	1	×	2	AWG	6.70	6.70	1.14	0.87	25.1	712
4	×	1	AWG	+	1	×	3	AWG	7.53	5.98	1.40	0.92	27.7	858
4	×	1	AWG	+	1	×	1	AWG	7.53	7.53	1.40	0.93	28.6	908
4	×	1/0	AWG	+	1	×	2	AWG	8.46	6.70	1.40	0.96	30.2	1035
4	×	1/0	AWG	+	1	×	1/0	AWG	8.46	8.46	1.40	0.98	31.1	1098
4	×	2/0	AWG	+	1	×	1	AWG	9.50	7.53	1.40	1.02	33.0	1254
4	×	2/0	AWG	+	1	×	2/0	AWG	9.50	9.50	1.40	1.04	34.1	1332
4	×	3/0	AWG	+	1	×	1/0	AWG	10.66	8.46	1.40	1.08	36.1	1528
4	×	3/0	AWG	+	1	×	3/0	AWG	10.66	10.66	1.40	1.10	37.3	1626
4	×	4/0	AWG	+	1	×	2/0	AWG	11.98	9.50	1.40	1.15	39.6	1868
4	×	4/0	AWG	+	1	×	4/0	AWG	11.98	11.98	1.40	1.17	41.0	1990
4	×	250	MCM	+	1	×	3/0	AWG	13.02	10.66	1.65	1.23	43.8	2253
4	×	250	MCM	+	1	×	250	MCM	13.02	13.02	1.65	1.25	45.1	2382
