UL83 44 XLPE Insulation Cable Xhhw Cable Xhhw Building Wire

Product Description

The XHHW cable wire is 600 volt. copper conductor XLPE insulation moisture /heat /low-temp /sunlight resistant, flame retardant thermoset
insulated wire and cable.

Applications

XHHW building wire is intended for general purpose applications utilized in conduit and tubing underground in conduit, or other recognized
raceways for services, feeders, and branch-circuit wiring as specified in the USA National Electrical Code (NEC). XHHW CU is permitted for
600-volt applications and can be used in wet locations at temperatures not to exceed 75ºC or dry locations at temperatures not to exceed90ºC.
It’s suitable for applications requiring low-leaking circuits and a dielectric constant of 3.5 or less. With the special insulation, the wire requires
no lubrication for installation.

Standards

XHHW complies with the following:
• ASTM B3, B8
• UL 44
• USA National Electrical Code, NFPA 70, 2014 Edition

Construction

Technical Parameter List

Packaging & Shipping

Cable will be packed and shipped on non-returnable wooden/wooden & iron/steel cable drum or recycled wooden box.

Our Services

We provide 24- hour service, you can contact +86-185 6701 6066 or by E-mail.
If you have any questions please feel free to contact us for more information and price.

Company Information

Hebei huatong wires & cables Group Co.,ltd.It was established in 1993, we are JV with Furukawa (Japanese company) for rubber serious
cables and JV with Riken(Japanese company) for elevator cables. Besides these,our submersible oil pump cable and shipboard cable are very
influential in domestic, and, the traditional cables are also produced such as PVC powercables, XLPE power cables, ABC cables, wires, control
cables, screened cables,communication cables, conductors.We areOEM for many USA, Europen, Australia cable company,70% of our products
are exported, most customers are from developed countries. We got ISO,UL, TUV,KEMA,CE and many other certifications.

Certificate

Now we got UL, TUV, CE, BV, KEMA, SABS, PSB products certifications and ISO9001, ISO14001, OHSAS18001 system certifications.
These UL certifications including AC, XHHW, THW/THHN, SER/SEU/MHF/UD, MV90/MV105,TC/TC-ER/, PV, MC,WELDING CABLES, SOOW/SJOOW,
DLO, MINING CABLES….

FAQ

Q1: What is your payment term?

A1: Our standard payment term is 30% for advanced payment before production, 70% before dispatch. However, the terms can be negotiable
as per different orders.


Q2: What is the lead time?

A2: The lead time can be 7 – 30 days according to actual order quantity.


Q3: What is the package of the cable?

A3: The package is steel & wooden drum or recycled wooden box. We can adopt other methods according to customer’s requirements.


Q4: How to choose cable if the type is undefined?

A4: Please provide the application, we will help you find the right type.
