UL719 Building Flat Electric Wires House Wire B Nm with Factory Price Nm-B

Electrical 600volts 14/2 12/3 12/2 Gauge with Ground Yellow 63 Copper Wire Nm-B Cable 1000 ft Non-Metallic Sheathed

1 Application:

Type NM-B (Non-metallic sheathed cable) has a broad range of usage as defined in Article 334 of the National Electrical Code (NEC). Type NM-B cable is commonly used for residential fixtures, switches, and loads rated for at least 90ºC. Type NM-B ampacity limitation shall be in accordance with the 60ºC conductor temperature rating, as specified in the National Electrical Code. Type NM-B is rated for 600 volts for both exposed and concealed work in normally dry locations. Type NM-B may be installed or fished in air voids and joints and in masonry block or tile walls where such walls are not exposed to, nor subject to, excessive moisture or dampness.

2 Standards:

Underwriters Laboratories Standards UL-83, UL-719

Federal Specification A-A-59544

ASTM-B3 and B8

ARRA 2009; Section 1605 “Buy American” Compliant

3 CONSTRUCTION:

Conductors:

Solid 14-10 AWG soft, uncoated copper, per ASTM-B3

Stranded 8 AWG conductor and larger uncoated, copper ASTM-B8

Insulation: Color-coded Polyvinyl Chloride (PVC) compound meeting the required thickness of Type THHN with a heat-stabilized Nylon jacket rated for 90°C in dry locations.

Grounding Conductor: Soft, uncoated copper per ASTM-B3 and/or ASTM-B8

Jacket: A 30-mil, color-coded, PVC jacket is applied over the completed assembly as follows:

14 AWG White I 12 AWG Yellow I 10 AWG Orange I 8 AWG Black I 6 AWG Black
