Introducing the UL4703 Listed/TUV/RoHS H1z2z2K UV Resistant DC 4mm 6mm PV/PV1f Wire for Solar Panel DC Cable 10AWG/12AWG – the epitome of excellence in solar panel cabling.

Ranked among the TOP TEN CABLE MANUFACTURERS IN CHINA.

Proudly the LARGEST CABLE MANUFACTURER IN NORTH CHINA.

Achieving an ANNUAL EXPORT VOLUME EXCEEDING 200 MILLION USD.

Certified by UL, TUV, KEMA, CE, BV, PSB, SABS, LLOYD’S, GL, NK, KR, and ABS – signifying global quality and trust.

Equipped with TUV TYPE TESTING REPORT for assured reliability.

Offering a WIDE RANGE OF PRODUCTS to meet diverse needs.

Accredited with ISO9001, ISO18001, OHSAS18001 SYSTEM CERTIFICATIONS for superior management practices.

Boasting a CNAS APPROVED LABORATORY for advanced testing and quality assurance.

High-performance H1Z2Z2-K cables.

Featuring Tinned Copper Conductor, Crosslinked LSZH insulation, and jacket. Rated for DC 1.5kV.

Single core cables designed for photovoltaic and solar systems. LSZH insulated and sheathed, flame retardant, halogen-free, and low smoke flexible cables for fixed installations. Proven durability through 20,000 hours of lifetime testing at 120°.

Ideal for the interconnection of photovoltaic system components. Suitable for fixed installations both outdoors and indoors, with or without protection, as well as within pipes, ducts, or similar closed systems. High ozone resistance ensures longevity.

Resilient against UV rays, oils, moisture, and harsh weather conditions. Designed for ambient temperatures up to 90°C (120°C under overload), using materials with a temperature index of 120°C according to Norm IEC 60216 (20,000 hours with 50% residual elongation). An expected lifespan of at least 25 years.

Insulation Colour: Black

Sheath Colour: Black/Red

Operating Temperature: -40°C to 90°C on theConductor

Overload Temperature: 120°C on theConductor

Expected Lifetime: 25+ YearsYears

Rated Voltage: Uo/U AC 0.6/1 kV, DC 1.5kV

Maximum Temperature in Case of Short Circuit: 250°C on the conductor (maximum duration 5seconds)

Minimum Bending Radius: 4 x outer diameter of theCable

Maximum Installation Temperature: -25°C

Print

HuatongCablesTUVEN50618H1Z2Z2-KDC1.5kV1×**mm2***M

Specification

Our Company

Hebei Huatong Wires & Cables Group Co., Ltd. was established in 1993. We have joint ventures with Furukawa (Japanese company) for rubber series cables and Riken (Japanese company) for elevator cables. Additionally, our submersible oil pump cable and shipboard cable hold significant influence domestically. We also produce traditional cables such as PVC power cables, XLPE power cables, ABC cables, wires, control cables, screened cables, communication cables, and conductors. Serving as an OEM for numerous cable companies in the USA, Europe, and Australia, 70% of our products are exported to developed countries. We are accredited with ISO, UL, TUV, KEMA, CE, and several other certifications.



Certificate

Laboratory



Our Services

1.With 24 years of production experience and 14 years of export experience, we ensure impeccable service. .

2. Products Certification: We are certified by UL, CE, BV, TUV, KEMA, PSB, SABS, ABS, NK, LR, KR, GL etc.

3. OEM service available based on official and legal authorization.

4. We maintain a strict quality control system.

5. Rapid delivery and feedback, ensuring faster lead times than our competitors.

6. Excellent quality at a reasonable price.

7. Strong technical support including technical data and drawings.

8. Our professional team provides active and dedicated service.

9. Stock availability and free samples for your convenience.

FAQ

1). When can I get the price?

We usually quote within 6 hours of receiving your inquiry. If you urgently need a quote, please call us or indicate the urgency in your email so we can prioritize your request.

2). How can I get a sample to check your quality?

After price confirmation, you can request samples to evaluate our quality. Samples are free, but the freight charge must be covered.

3). How long can I expect to get the sample?

Once you pay the freight charge and send us the confirmed files, samples will be ready for delivery within 3-7days.Samples will be sent via express and should arrive in 3-5 days. You can use your own express account or prepay us if you do not have an account.

4). What about the lead time for mass production?

The lead time depends on the order quantity and the season. Our record is delivering 10 kilometers of cable within a week. Generally, we recommend starting inquiries two months before your desired delivery date to ensure timely arrival.
