UL1569 Standard Aluminum Armour Alloy Metal Clad Type Mc Building Cable, 600V

HUA TONG Type MC cable can be used for feeder and branch circuit line as specified in NEC.The insulation wire core of type MC cable is XHHW-2, it can be used in dry and wet locations with the highest working temperature not exceed 90. The rated voltage of type MC cable is 600V. The cable consists three or four xlpe insulated phase cores plus one bare ground conductor. Interlocked-aluminum armour tape is applied overall the cable. PVC jacked is optional. MC cable with PVC jacket provides extra durability.long-term reliability and installation security.

ASTM-B,B-801 and B-836

UL standard 44 for XHHW-2

UL Standard 1569

RoHS environmental conductive requirement


Conductor: AA-8030 aluminum alloy conductors

Insulation: Cross-linked polyethylene(XLPE) insulation

Armor:Interlock aluminum tape armor

Temperature Range: Temperature of 90 C in wet and dry locations

Environmental: Free of harmful heavy metals in compliance with RoHS

Voltage Rating:600Volt


The AA-8000 aluminum alloy conductor is applied in Type MC cable. Its insulated core is complied to the requirement of Type XHHW-2 in UL44. Insulation material is cross-linked polyethylene(XLPE) with characteristics property,which can meet the FT2 level combustion test requirement.

MC cable, USA, UL & NEC standard, armored cable, metal clad cable, AC cable, BX cable, TECK cable, interlocked armored cable.

Hebei Huatong Wires and Cables Group Co., Ltd. was established in 1993. Yearly export amount more than 800million.We own more than 420 sets manufacturing equipment and  250 sets of testing equipment or apparatus. And with CNAS accredited national level laboratory.Our annual production capacity is 5 billion Yuan.We have 1200 employers, among which 150  are technicians. Based on the scientific management, now we are a comprehensive, large-scale enterprises in wire and cable industry.Voltage up to 35KV, including XLPE power cables,PVC power cables, mining cables, rubber cables for general purpose, Submersible oil pump cables, solar cables, shipboard cables,lead sheath cables, aerial cables, control and instrument cables, special cables etc.Products are exported to USA, Australia, Singapore, Europe, South America, Middle East, Asia, Africa and soon.

1.22 years production experience and 13 years export experience .

2.Products certification :UL,CE,BV,TUV,KEMA,PSB,SABS,ABS,NK,LR,KR,GL etc

3. OEM service available based on official & legal authorization.

4.Strict quality control system.

5.Rapid delivery and feedback  Faster lead time than our competitors.

6.Excellent quality with reasonable price.

7. Strong technical support (technical data, drawing, etc.)

8.Professional teamwork service for you actively.

9.Stock available, Free sample is available.
