Product Details
Product Description
XHHW-2/PVC Circuit | Tray Cable TCP Cable with UL Certification for USA
In free air, raceways or direct burial
In wet or dry locations
Permitted for use in Class I, Division 2 industrial hazardous locations per NEC
Permitted for Exposed Run (ER) use in accordance with NEC
Standard
UL 1277
Cable Construction
Conductor: 14 AWG thru 750 kcmil bare, annealed copper per ASTM B3 Class B stranding per ASTM B8
Insulation: Flame-retardant Cross-linked Polyethylene (XLPE) Color-coded per ICEA Method 4; individual conductors colored black with conductor number surface printed in contrasting ink
Ground: Uninsulated bare annealed copper per ASTM B3 Class B stranding per ASTM B8
Jacket: Lead-free, flame-retardant, sunlight-resistant Polyvinyl Chloride (PVC)
Cable Parameters
|
|
|
|
Insulation Thickness |
Min. Avg. Jacket Thickness |
NOMINAL CABLE O.D. |
|||
|
number of Cond. |
Cond. Size (AWG) |
Cond. Strand. |
Ground Wire Size (AWG) |
IN |
MM |
IN |
MM |
IN |
|
14 AWG – 750 kcmil MULTI-CONDUCTORS |
||||||||
|
3 |
14 |
7/.0242 |
14 |
0.030 |
0.76 |
0.045 |
1.14 |
0.390 |
|
3 |
12 |
7/.0305 |
12 |
0.030 |
0.76 |
0.045 |
1.14 |
0.435 |
|
3 |
10 |
7/.0385 |
10 |
0.030 |
0.76 |
0.060 |
1.52 |
0.485 |
|
3 |
8 |
7/.0486 |
10 |
0.045 |
1.14 |
0.060 |
1.52 |
0.640 |
|
4 |
8 |
7/.0486 |
10 |
0.045 |
1.14 |
0.060 |
1.52 |
0.705 |
|
3 |
6 |
7/.0612 |
8 |
0.045 |
1.14 |
0.060 |
1.52 |
0.720 |
|
4 |
6 |
7/.0612 |
8 |
0.045 |
1.14 |
0.060 |
1.52 |
0.790 |
|
3 |
4 |
7/.0772 |
8 |
0.045 |
1.14 |
0.080 |
2.03 |
0.875 |
|
4 |
4 |
7/.0772 |
8 |
0.045 |
1.14 |
0.080 |
2.03 |
0.950 |
|
3 |
2 |
7/.0974 |
6 |
0.045 |
1.14 |
0.080 |
2.03 |
1.000 |
|
4 |
2 |
7/.0974 |
6 |
0.045 |
1.14 |
0.080 |
2.03 |
1.095 |
|
3 |
1 |
19/.0664 |
6 |
0.055 |
1.40 |
0.080 |
2.03 |
1.120 |
|
4 |
1 |
19/.0664 |
6 |
0.055 |
1.40 |
0.080 |
2.03 |
1.235 |
|
3 |
1/0 |
19/.0745 |
6 |
0.055 |
1.40 |
0.080 |
2.03 |
1.215 |
|
4 |
1/0 |
19/.0745 |
6 |
0.055 |
1.40 |
0.080 |
2.03 |
1.340 |
|
3 |
2/0 |
19/.0837 |
6 |
0.055 |
1.40 |
0.080 |
2.03 |
1.310 |
|
4 |
2/0 |
19/.0837 |
6 |
0.055 |
1.40 |
0.080 |
2.03 |
1.450 |
|
3 |
3/0 |
19/.0940 |
4 |
0.055 |
1.40 |
0.080 |
2.03 |
1.420 |
|
4 |
3/0 |
19/.0940 |
4 |
0.055 |
1.40 |
0.080 |
2.03 |
1.570 |
|
3 |
4/0 |
19/.1055 |
4 |
0.055 |
1.40 |
0.080 |
2.03 |
1.540 |
|
4 |
4/0 |
19/.1055 |
4 |
0.055 |
1.40 |
0.110 |
2.79 |
1.765 |
|
3 |
250 |
37/.0822 |
4 |
0.065 |
1.65 |
0.110 |
2.79 |
1.750 |
|
4 |
250 |
37/.0822 |
4 |
0.065 |
1.65 |
0.110 |
2.79 |
1.930 |
|
3 |
350 |
37/.0973 |
3 |
0.065 |
1.65 |
0.110 |
2.79 |
1.970 |
|
4 |
350 |
37/.0973 |
3 |
0.065 |
1.65 |
0.110 |
2.79 |
2.180 |
|
3 |
500 |
37/.1162 |
2 |
0.065 |
1.65 |
0.110 |
2.79 |
2.250 |
|
4 |
500 |
37/.1162 |
2 |
0.065 |
1.65 |
0.110 |
2.79 |
2.475 |
|
3 |
750 |
61/.1109 |
1 |
0.080 |
2.03 |
0.140 |
3.56 |
2.810 |
|
4 |
750 |
61/.1109 |
1 |
0.080 |
2.03 |
0.140 |
3.56 |
3.115 |
We are China UL1277 Shielded Unshielded Multi-Conductor Epr/CPE Tray Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
