UL1276 Standard Welding Cable 1/0 AWG 600V

UL1276 Standard Welding Cable 1/0 AWG 600V image

Get Latest Price Request a quote

Product Details

Model NO.

6 AWG-500MCM

Application

Welding Machine

Conductor Material

Flexible Copper Wire

Sheath Material

EPDM

Insulation Material

EPDM

Material Shape

Round Wire

Range of Application

Welding Machine

Certification

ISO9001, CE

Brand

Rne Da

Voltage

600V

Cross Section

6AWG 4AWG 3AWG 1/0AWG 2/0AWG 3/0AWG 4/0AWG

Sheathed

EPDM

Certificate

Product

Welding Cable

Conductor

Flexible Copper Wire

Standard

UL1276

Transport Package

Soft Packing in Coil,100m/Roll,or as Your Requests

Specification

UL1276

Trademark

RNE DA

Origin

Hebei, China

HS Code

85444921

Production Capacity

500km/Month

Product Description

UL1276 standard 600V 4/0awg flexible copper EPDM sheathed welding cable with UL listed

Application:

Designed as secondary voltage resistance welding cable leads, Battery cables, Temporary power uses, Power supply applications not exceeding 600V AC.

Structure:

Conductor: Class k Stranded copper ASTM B-172
Insulation: Rubber

Standard:

UL1276

UL File No.:

E477543

Voltage:

600V

Working temperature:

–50°C to + 105°C

Performance:

Outstanding cut, abrasion and slag resistance

Resistant to oil, chemicals, water, ozone, & solvents

Size AWG /Kcmil	Conductor	Nominal Insulation		Overall	Weight	Max. DC resistance at 20C (Ω/km)
	Diameter	Thickness		Diameter
	mm	mm	mil	mm	kg/km
6AWG	5.10	1.65	65	8.6	178	1.380
4AWG	6.10	1.65	65	9.6	240	0.865
2AWG	8.10	1.65	65	11.5	371	0.549
1AWG	9.00	2.03	80	13.2	472	0.436
1/0AWG	10.10	2.03	80	14.3	582	0.345
2/0AWG	11.50	2.03	80	15.7	715	0.276
3/0AWG	12.90	2.03	80	17.1	884	0.219
4/0AWG	14.70	2.03	80	18.9	1119	0.173
250MCM	16.20	2.41	95	21.1	1373	0.147
350MCM	18.90	2.41	95	23.9	1837	0.106
500MCM	23.10	2.41	95	28.0	2633	0.074

The largest UL cable manufacturer in China

Top 10 Cable manufactuer in China.

Largest Rubber cable manufacturer in China.
Leading ESP cable manufacturer.
Professional OEM manufacturer.
With UL,TUV,KEMA,CE,BV,PSB,SABS,MSHA,GL,NKK,KR,DNV,CCS certifications.
With TUV TYPE TESTING REPORT.

With ISO9001,ISO14001,ISO45001 syetem certifications.
ISO 17025 standard and CNAS approval laboratory.

We’ll be happy to give a quotation upon receipt your detailed requirements.

We are China UL1276 Standard Welding Cable 1/0 AWG 600V manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
