UL1015 600V Copper Wire PVC Insulated Awm/Mtw/Machine Tool Wire

UL1015 600V Copper Wire PVC Insulated Awm/Mtw/Machine Tool Wire image

Get Latest Price Request a quote

Product Details

Model NO.

AWM wire

Application

Overhead

Conductor Material

Copper

Sheath Material

PVC

Insulation Material

PVC

Material Shape

Round Wire

Range of Application

Commercial or Industrial Applications

Certification

ISO9001, RoHS

Brand

Renda

Sample Available

Yes

Colors

All Color Available

Customized

Yes

Package

as Per Your Request

Transport Package

Roll, Reel, Coil as Your Requirements

Specification

18AWG 16AWG 14AWG 12AWG 10AWG 8AWG 6AWG

Trademark

RENDA

Origin

China

HS Code

8544492100

Production Capacity

10000000FT/Month

Product Description

600V 3.5mm2 5.5mm2 60mm2 250mm2 PVC insulated Philippines thhn wire cable

Internal wiring of electrical and electronic equipment and appliances, internal wiring of panels and meters, point to point wiring

– UL 1015, 105°C, 600V – UL 1032, 90°C, 1000V
– UL MTW – CSA TEW 105°C 600V – VWI/FTI – 6 AWG – 4/0: 1232/1284/1338 600V or 10269 1000V

– 8 AWG & larger – stranded bare copper or tinned copper
– 10 AWG – 16 AWG – stranded tinned copper
– 20 AWG – 24 AWG – stranded or solid tinned copper
– 18 AWG – solid bare, stranded tinned
– Other conductor types and strandings available by request

Size AWG /Kcmil	Number of strands (Nos)	Min. Average Insulation		Overall	Approx. cable weight (kgs/km)
		Thickness		Diameter
		mil	mm	mm
24	7	30	0.76	2.13	14.81
22	17	30	0.76	2.28	18.01
20	26	30	0.76	2.46	22.67
18	41	30	0.76	2.7	29.98
17	52	30	0.76	2.085	35.13
16	26	30	0.76	3.02	41.27
14	41	30	0.76	3.4	57.98
13	52	30	0.76	3.63	69.90
12	65	30	0.76	3.88	83.76
11	82	30	0.76	4.18	101.61
10	105	30	0.76	4.67	126.49
9	126	30	0.76	4.97	148.12
8	161	45	1.14	6.18	204.79
7	203	45	1.14	6.67	248.83
6	252	60	1.52	7.93	326.95
5	324	60	1.52	8.91	407.57
4	408	60	1.52	9.63	495.51
3	513	60	1.52	10.09	598.91
2	646	60	1.52	10.96	734.09
1	817	80	2.03	12.98	966.52
1/0	1026	80	2.03	14.06	1179.95
2/0	336	80	2.03	15.83	1468.44
3/0	418	80	2.03	17.20	1787.54
4/0	525	80	2.03	18.79	2200.21

We are China UL1015 600V Copper Wire PVC Insulated Awm/Mtw/Machine Tool Wire manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
