UL Standard Household Copper PVC Insulated Wire Cable

UL Standard Household Copper PVC Insulated Wire Cable image

Get Latest Price Request a quote

Product Details

Model NO.

Household PVC Cable

Application

Heating, Underground, Household, Building

Conductor Material

Copper

Sheath Material

Nylon

Insulation Material

PVC

Material Shape

Round or Sector

Range of Application

Flame Retardant

Certification

ISO9001, CE, CCC, RoHS, VDE

Brand

Rneda

Product Name

Thhn Building Cable

Conductor

Copper or Aluminum

Voltage

600V

Insulated Material

PVC

Sheathed Material

Nylon

Certificate

Standard

UL83

Core

Single

Cross Section

14AWG 12AWG 10AWG 8AWG 6AWG

Sample

Free

Transport Package

Soft Packing

Specification

14--6AWG

Trademark

RNEDA

Origin

Hebei, China

HS Code

85444921

Production Capacity

500km Per Month

Product Description

UL Standard Household Copper PVC Insulated Wire Cable

APPLICATIONS

THHN or THWN-2 conductors are primarily used in conduit and cable trays for services, feeders, and branch circuits in commercial or industrial applications as specified in the National Electrical Code. Voltage for all applications is 600 volts.

When used as type THHN, conductor is suitable for use in dry locations at temperatures not to exceed 90°C.

When used as type THWN, conductor is suitable for use at temperatures not to exceed 90°C, dry locations or 75°C
wet locations or not to exceed 75°C when exposed to oil or coolant.
When used as type THWN-2, conductor is suitable for use in wet and dry locations at temperatures not to exceed 90°C or not to exceed 75°C when exposed to oil or coolant. Conductor temperatures not to exceed 105°C in dry locations when rated AWM and used as appliance wiring material. Voltage rating for all applications is 600 volts.

SPECIFICATIONS

THHN or THWN-2 comply with:

ASTM – B3, B8 (7,19, 37, 61 Strands), B 787 (19 Wire Combination Unilay Strand) Technical Compliance

UL 83 – Thermoplastic-Insulated Wires and Cables

CSA C22.2 No. 75-03

UL 1063 (MTW) – Machine-Tool Wires and Cables (stranded cables only)

UL 758 (AWM)

ICEA S-95-658/NEMA WC 70

Cable Construction

Conductor:

Soft annealed bare copper, Class B stranding per ASTM B8

Insulation:

Tough, heat and moisture resistant Polyvinyl chloride (PVC) insulation over which a nylon jacket is applied.

Color:option

Cable Parameter

AWG OR KCMIL	STRAND	NOMINAL INSULATION THICKNESS INCH/MM		NOMINAL JACKET THICKNESS INCH/MM		NOMINAL OVERALL DIAMETER INCH/MM		CABLE WEIGHT LBS/KFT KG/KM
14	1	0.015	0.38	0.004	0.10	0.11	2.79	15	22
12	1	0.015	0.38	0.004	0.10	0.12	3.05	23	34
10	1	0.020	0.51	0.004	0.10	0.15	3.81	37	54
14	19	0.015	0.38	0.004	0.10	0.11	2.79	16	24
12	19	0.015	0.38	0.004	0.10	0.13	3.30	24	36
10	19	0.020	0.51	0.004	0.10	0.17	4.32	39	58
8	19	0.030	0.76	0.005	0.13	0.22	5.59	63	94
6	19	0.030	0.76	0.005	0.13	0.26	6.60	98	145
4	19	0.040	1.01	0.006	0.15	0.33	8.38	157	234
3	19	0.040	1.01	0.006	0.15	0.36	9.14	193	287
2	19	0.040	1.01	0.006	0.15	0.39	9.91	240	357
1	19	0.050	1.27	0.007	0.18	0.43	10.92	300	446
1/0	19	0.050	1.27	0.007	0.18	0.47	11.94	376	560
2/0	19	0.050	1.27	0.007	0.18	0.52	13.21	467	695
3/0	19	0.050	1.27	0.007	0.18	0.57	14.48	581	864
4/0	19	0.050	1.27	0.007	0.18	0.64	16.26	724	1077
250	37	0.060	1.52	0.008	0.20	0.69	17.53	855	1272
300	37	0.060	1.52	0.008	0.20	0.76	19.30	1022	1521
350	37	0.060	1.52	0.008	0.20	0.79	20.07	1191	1772
400	37	0.060	1.52	0.008	0.20	0.85	21.59	1345	2001
500	37	0.060	1.52	0.008	0.20	0.94	23.88	1668	2482
600	61	0.070	1.78	0.009	0.23	1.10	27.94	1994	2967
750	61	0.070	1.78	0.009	0.23	1.16	29.46	2465	3668

Certificate

USA is our main market. We have many distributors from USA companies. And we have obtained UL certifications for many products, such as TC cable, DLO cable,RHH/RHW/RHW-2/XHH/XHHW/XHHW-2/SIS, THHN/THHW/THW/THW-2/THWN/THWN-2/TW,SER/SEU/USE/USE-2/MHF, MV-90/MV-105, TC cable, MC cable, DLO, type DG, PV wire, AC Cable, Soow, Welding cable and so on

Company information:
1 Location:

Hebei Huatong wires and cables group co., ltd. is Located in Tangshan city, 100 Km to Tianjin Xingang sea port, 150Km to the Capital city Beijing China.

2 About Huatong:

Founded in 1993 Registered capital: CNY294 Million Equal to: US$45 Million
Floor space: 220,000 square meter Employees: 950 Production capacity:US$500Million

3 Production and inspection facility:

Drawing machine : 50 sets
Conductor stranding machine: 30sets
CCV and CV extruding line: 30sets
Insulation and sheath extruding machine: 40sets
Cabling machine: 30sets
Braiding machine:40sets
Other auxiliary machine: 150stes
MV cable partial discharge
equipment: 4sets
Other test machine:100sets

4 Enterprise Principle:

Strengthening Huatong /Benefiting employees /Serving our country and society/Aiming to be a world-renowned enterprise

Our Service:

1.25 years production experience and 13 years export experience .

2.Products certification :UL,CE,BV,TUV,KEMA,PSB,SABS,ABS,NK,LR,KR,GL etc

3. OEM service available based on official & legal authorization.

4.Strict quality control system.

5.Rapid delivery and feedback Faster lead time than our competitors.

6.Excellent quality with reasonable price.

7. Strong technical support (technical data, drawing, etc.)

8.Professional teamwork service for you actively.

9.Stock available, Free sample is available.

FAQ:

1.How many year have our factory producing power cable?

Our factory produce power cable for 25 years.

2 How Long time the customer can get the new price after get your inquiry?

Usually , one hour is ok for us , because we are factory , we calculate the price by ourselves.

3.Which port our factory is near to?

Tianjin , Qingdao port.

4.What payment terms do we accept?

T/T 30% in advance and balance before shipping the product or L/C 100% at sight are both ok.

5.What about the package for our power cable?

It is usually packed in strong wooden drum.The drum size is usually:2.0m x 1.25m x 1.12m x 1.4m which suitable for container , we can do it according to customer requirements.

6.How long meter power cable for one wooden drum?

This is according to power cable’s diameter and customer’s requirements.

7.How about our delivery time?

According to your order’s quantity , for 1million meters power cable, 25 working days is ok.

8.Do we provide sample for free?

Yes , we provide the sample to you for free , you only need pay for the freight cost.

We are China UL Standard Household Copper PVC Insulated Wire Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
