UL Certified PVC Insulation 600V 12 AWG Wire Thhn Copper Conductor PVC Insulation Nylon Sheath Electrical Wire

Applications:

1. Type TW, THW, THHN, THWN, TFF building wire is engineered for general-purpose applications as outlined by the National Electrical Code (NEC), ensuring reliability and safety.

Type TW, THW, THHN, THWN, TFF is ideal for both new construction and rewiring projects for 600-volt applications and is perfect for environments requiring Type THHN or THWN standards.

2. The conductor is suitable for use in both wet and dry locations at temperatures up to 90°C, or up to 75°C in the presence of oil or coolants, providing versatile application options.

For environments needing Type MTW conductors, this wire performs efficiently in dry locations at 90°C, or wet locations at temperatures up to 60°C, including areas exposed to oils or coolants.

Applications demanding Type AWM conductors can rely on this wire for dry locations with temperatures up to 105°C, ensuring high adaptability and performance.

Features:

Designed with a Nylon outer jacket for effortless pulling, this wire is VW-1 rated for 14 AWG – 8 AWG and is resistant to gasoline and oil, ensuring robustness and durability.

Jacket:

Constructed with a tough, polyamide, Nylon outer covering conforming to UL-1063 and UL-83 standards.

Standards:

Complies with Underwriters Laboratories Standards UL-83, UL-1063, UL-758,

AWM Spec 1316, 1317, 1318, 1319, 1320, 1321,

ASTM Stranding Class B3, B8, B787,

Federal Specification A-A-59544,

Canadian Standards Association C22.2 No. 75,

NEMA WC70/ICEA S-95-658,

Institute of Electrical and Electronics Engineers.

Construction:

BUILDING WIRE:

UL Listed Types TW, THW, THHN, THWN, TFF, TFFN,

Insulation: PVC (Poly Vinyl Chloride) with optional Secondary Nylon Jacket,

Conductor: Bare Copper, Voltage Rating: 600 Volts.



FAQ:

(1) When can I get the price?

We typically respond with a quote within 6 hours of receiving your inquiry. If you need the price urgently, please call us or indicate the urgency in your email, and we will prioritize your request.

(2) How can I get a sample to check your quality?

Once the price is confirmed, you can request samples to evaluate our quality. The samples are free, but the freight charges will apply.

(3). How long can I expect to get the sample?

After you cover the freight charges and send us the confirmed files, our team will prepare the samples for delivery within 3-7 days. The samples will be dispatched to you

via express shipping and should arrive within 3-5 days. You have the option to use your own express account or prepay us if you don’t have one.

(4). What about the lead time for mass production?

The lead time for mass production largely depends on the order quantity and the season in which the order is placed. Our best record is delivering 10 kilometers of cable within

a week. Generally, we recommend starting your inquiry two months before you need the products in your country to ensure timely delivery.
