UL Certification 600V Installation Tfl Cable

UL Certification 600V Installation Tfl Cable image

Get Latest Price Request a quote

Product Details

Model NO.

TFL cable

Current

DC Cable

Insulation Material

Sheath Material

Material Shape

Flat Wire

Wire Core Material

Bare Copper Wire

Model

Tfl

Brand

Rneda

Temperature

75-90degree

Transport Package

Soft Packing or Standard Export Drums

Specification

Trademark

RNEDA

Origin

China

HS Code

8544492100

Production Capacity

1000000meter Per Month

Product Description

Flat Flexible elevator rubber cables

Application

Halogen free, flexible connecting cable for fixed installation. Intended for power supply of telecom equipment, where there are requirements for low inductance and good temperature resistance. Grey jacket for indoor use. Black jacket is sunlight resistant, UV stabilized, for outdoor use.

Structure

Conductor

Stranded, tinned, annealed copper, IEC 60228 class 5. Three parallel cores to form a flat conductor.

Insulation

Flame retardant polyolefin black and grey.

Shield

Inner: aluminum polyester shield 100% coverage

Outer: Tinned copper Clad aluminum or tinned copper wire braid

Sheath

Flame retardant polyolefin , grey or black

Operating voltage

Max. 90 ºC,dry

Fire resistance

IEC 60332-3 cat C

UL 1685, Vertical tray

Standard:

UL2731, Telecommunication Central Office Power, Battery, and Distribution Cables

Technical data

Model	Conductors x size	Approx. Height x width	Weight Kg/100m		Max. DC resistance at 20ºC
Model	(mm2)	mm	With tinned copper wire braid	With tinned copper clad aluminium alloy braid	Ω/km
TFL 492322	2X2.5mm2(14AWG)	7.3*7.0	10	9.7	8.21
TFL 492324	2X6mm2(10AWG)	9.5*9.5	19.3	18.5	3.39
TFL 492324/0	2X6mm2(10AWG)	9.5*9.5	19.3	18.5	3.39
TFL 492325	2X10mm2 (8AWG)	10.5*11.5	29.2	27.9	1.95
TFL 492325/0	2X10mm2 (8AWG)	10.5*11.5	29.2	27.9	1.95
TFL 492326/0	2X16mm2 (6AWG)	11.8*13.6	42.2	40.8	1.24

We are China UL Certification 600V Installation Tfl Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
