UL Certificate UL Listed 250-FT 14 - 2 12-2 12-3 10-2 10-3 Solid Aluminum Mc Cable Aluminum Armored Mc Cable Metal Clad Mc Cable Aluminum Mc Wire

UL Certificate UL Listed 250-FT 14 - 2 12-2 12-3 10-2 10-3 Solid Aluminum Mc Cable Aluminum Armored Mc Cable Metal Clad Mc Cable Aluminum Mc Wire image

Get Latest Price Request a quote

Product Details

Model NO.

MC cable

Current

DC & AC

Insulation Material

PVC

Sheath Material

Aluminum Alloy Tape

Material Shape

Round Wire

Wire Core Material

Red Copper Wire

Certification

ISO, CCC, CE

Model

PVC Cables

Brand

Rneda

Conductor

Thhn

Core

2 3

Armor

Aluminum Alloy

Rated Voltage

600V

Standard

UL 83/1569

Products Name

Mc Cable Bx Cable AC Cable

Armor Material

Steel or Aluminum

Type

Building Wire

Transport Package

Steel-Wooden Drum, Steel Drum

Specification

UL1277

Trademark

RNEDA

Origin

China

HS Code

8544492100

Production Capacity

1000m/Month

Product Description

Hebei huatong wires&cables Group Co.,ltd.

Largest cable manufacture in north China

14 years export experience

With UL,TUV,KEMA,CE,BV,PSB,SABS,GL,NK,KR,ABS ..products certifications

ISO9001,ISO14001,OHSAS18001 system certifications

With authorities testing report

CNAS approval laboratory

General description:

This category covers Type MC metal-clad cable. The cable is rated for use up to 2000 V, and certified in sizes 18 AWG through 2000 kcmil for copper, 12 AWG through 2000 kcmil for aluminum or copper-clad aluminum, and employs thermoset or thermoplastic insulated conductors. It is intended for installation in accordance with Article 330 ofANSI/NFPA 70, “National Electrical Code” (NEC).

Description of purpose:

MC cable is suitable for use as bellow:

1.Branch,feeder and service power distribution

2.Power,lighting,control and signal circuit.

3.Fished or embedded in plaster

Detailed products description:

1,UL standard:UL1569

2.MC cable(Metal clad)

3.specification:14awg-4/0awg

4.voltage rate:600v

MC cable, USA, UL & NEC standard, armored cable, metal clad cable, AC cable, BX cable, TECK cable, interlocked armored cable

Armor	Interlocked Aluminum Strip
Inner Conductor	Solid/ Stranded Copper
Conductor Insulation	THHN/ THWN OR XHHW-2
Assembly Covering	Polypropylene Tape
Temperature Rating	≤ 90 (dry); ≤ 75 (wet)
Grounding	Insulated Green Grounding Conductor
Voltage Rating	600V

We are China UL Certificate UL Listed 250-FT 14 - 2 12-2 12-3 10-2 10-3 Solid Aluminum Mc Cable Aluminum Armored Mc Cable Metal Clad Mc Cable Aluminum Mc Wire manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
