UL Certificate 44 Standard 600V Single Core Xhhw Xhhw-2 Wire

UL Certificate 44 Standard 600V Single Core Xhhw Xhhw-2 Wire image

Get Latest Price Request a quote

Product Details

Model NO.

XHHW

Application

Heating, Building

Conductor Material

Aluminum 8000

Sheath Material

None

Insulation Material

XLPE

Material Shape

Round Wire

Range of Application

Conduit or Recognized Raceways for Services

Certification

ISO9001, CE, CCC, RoHS, VDE

Brand

Huatong

Characteristic

High Heat Water Resistant

Certificate

Package

Drums

Performance

Sun Res

Transport Package

Coils and Drums

Specification

14awg-1000mcm

Trademark

Renda

Origin

China

HS Code

8544492100

Production Capacity

200000m/Month

Product Description

Type XHH XHHW XHHW-2

crosslinked polyethylene (XLPE) AA-8000 series aluminum alloy(copper)

Application:

HUATONG XHHW-2 Cable consists of aluminum alloy conductor with a specially designed XLPE insulation. It can reduce half pulling force than the regular XHHW-2.Its primarily used in conduit or recognized raceways for services,feeders, and branch circuit wiring as specified in the National Electrical Code.

Structure:

1. Conductor: soft plain copper, conforms to ASTM B3, B8.

compact soft drawn aluminum alloy,conforms to ASTM-B-800,B-801andB-836

2. Insulation: crosslinked polyethylene (XLPE)

Standard:

UL44

UL File No.:

E466693

Voltage:

600V

Working temperature:

in dry or wet locations at temperature not to exceed 90°C.

Performance:

Abrasion, heat, moisture, and flame Resistant.

Printing:

HT CABLES (UL) E468871 Type XHHW-2 *AWG 600V 90C DRY OR WET SUN RES 2023 ****FT

Technical data: XHHW-2-ALUM

Conductor Size (AWG, Kcmil)	Phase Conductor Diameter		Nominal Insulation Thickness		Nominal Overall Diameter		Approx. Weight		Allowable Ampacity AMPS
Conductor Size (AWG, Kcmil)	inch	mm	mils	mm	mils	mm	kg/km	lbs/1000ft	60C	75C	90C
8	0.134	3.4	45	1.14	224	5.7	41.26	28	35	40	45
6	0.169	4.29	45	1.14	259	6.6	58.21	39	40	50	55
4	0.213	5.41	45	1.14	303	7.7	84.12	57	55	65	75
2	0.268	6.81	45	1.14	358	9.1	123.33	83	75	90	100
1	0.299	7.59	55	1.4	409	10.4	159.21	107	85	100	115
1/0	0.336	8.53	55	1.4	446	11.3	193.47	130	100	120	135

XHHW-2-Copper

Conductor		Insulation	Nominal	Approx. Net Wt.	Allowable Ampacities
Size(AWG or Kcmil)	No.of strands	Thickness	.D. O	Per 1000′	60°C	75°C	90°C
Size(AWG or Kcmil)	No.of strands	(mils)	(mils)	(lbs.)	60°C	75°C	90°C
14	7	30	130	18	15	15	15
12	7	30	162	37	20	20	20
10	7	30	171	40	30	30	30
8	7	45	232	65	40	50	55
6	7	45	268	96	55	65	75

UL Certificate for XHHW,SER,SEU,MC Cable

We are China UL Certificate 44 Standard 600V Single Core Xhhw Xhhw-2 Wire manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
