UL Approved Type G G-Gc Shd-Gc Portable Power and Mining Cable

UL cUL MASH certificate Mining Cable SHD-GC Type W Type G

Application:

Type G-GC cables are designed for use in industrial and light-to-medium duty mining applications. These cables are often used on three-phase AC systems where 3 or 4 conductors are needed and grounding is required. This construction has a ground check as a safety mechanism to ensure the equipment is fully grounded.


Use on AC off track equipment such as long wall miners loaders, drills, shovels, conveyors, pumps, and mobile equipment requiring grounding conductors and a ground check conductor and metallic shielding overall other industrial, mining applications.

Maximum continuous conductor temperature is 90⁰C.

Structure:

1. Conductor: 6 AWG thru 500 kcmil coated annealed copper, bunched wires, rope-lay-stranded per

ASTM B172.

2. Insulation: Ethylene propylene Rubber (EPR) insulation.

3.  Insulation Shield: A flexible coated copper/textile braid shield is applied over non-conducting overlapped           tape.

4. Ground-Check Conductor:

Annealed copper, rope-lay-stranded per ASTM B172, insulated with high-strength yellow polypropylene.

5. Grounding Conductors:

   Coated copper, rope-lay-stranded per ASTM B172.

   Two conductors in contact with the flexible copper braid shield.

6. Separator:Polyamide open braid applied overall.

7. Jacket:

    Flame retardant, thermosetting Chlorinated Polyethylene (CPE).

Standard:

ICEA S-75-381 Portable and Power Feeder Cables for use in mines and similar applications.

Meets flame test requirements and is accepted for listing by MSHA.

UL File No.:

E482608

Voltage:

2000V

Working temperature:

 in dry locations only at temperature not to exceed 90°C.

Performance:

Excellent flexibility ;

Highly ozone, sun, weather and flame resistant ;

Oil and heat resistant.

Technical data:

TYPE SHD-GC – 2000 V
