UL Approved 600V Jz-602-PUR Oz-602-PUR Flexible PUR Control Cable

UL Approved 600V Jz-602-PUR Oz-602-PUR Flexible PUR Control Cable image

Get Latest Price Request a quote

Product Details

Model NO.

JZ-602-PUR OZ-602-PUR

Application

Heating, Industrial

Conductor Material

Copper

Sheath Material

PVC

Insulation Material

PUR Rubber

Material Shape

Round Wire

Certification

CE, VDE, UL

Brand

Huadong

Rated Voltage

600V

Core

2, 3, 4, 5, 7, 10, 12, 18, 25, 34, 42 Core etc

Size

0.5 0.75 1 1.5 2.5 4 6 10mm2 or AWG

Sample

Available

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

JZ-602-PUR / OZ-602-PUR 80°C , 600 V

Application:

UL and CSA approved flexible control cable rated at 600 V, primarily designed for exporters to the US or Canadian market. Used in machine tools, control systems, connection between control panels and machines, assembly lines and other industrial equipment. Suitable for installation in dry, moist, wet and outdoor environment and moderate flexing applications.

Properties:
1.Resistant to: oil, UV radiation, ozone, oxygen, weathering effects, hydrolysis, microbes, coolants, hydraulic fluids,
acids, alkalis, greases, seawater and wastewater
2.Highly abrasion-resistant, notch-resistant, tear-resistant, cut-resistant,wear-resistant, low adhesion for outdoor use
3.The materials used during manufacturing are cadmium-free, contain no silicone and are free from substances harmful to the wetting properties of lacquers
Cable Structure:

* Copper wire bare, finely stranded acc. to DIN VDE 0295 Class 5 / IEC 60228 Class 5

* Core insulation: PVC acc. to UL-Std. 758 (AWM) Style 10012, CSA-Std. C22.2 No. 210

* Core identification acc. to DIN VDE 0293-334, black cores with consecutive labeling in white digits

* Protective conductor: starting with 3 cores,

G = with protective conductor GN-YE, in the outer layer,

x = without protective conductor (OZ)

* Cores stranded in layers with optimal lay lengths

* Outer sheath: Special grade of full polyurethane

* Sheath colour: grey (RAL 7001)

* Length marking: in metres

Specification:

PUR control and connection cable acc. to UL-Std. 758 (AWM) Style 20939, CSA-Std. C22.2 No. 210 – AWM I/II A/B
Temperature range
flexible -5°C to +80°C
fixed -40°C to +80°C
Nominal voltage UL (AWM) AC 600 V
Test voltage core/core 3000 V
Breakdown voltage 6000 V
Minimum bending radius
flexible 7.5x Outer-Ø
fixed 4x Outer-Ø

Cable Parameter:

No. cores x cross-sec. mm	AWG, approx.	Outer Dia mm, approx.	Cu factor per km	Weight kg/km, approx.
2×0.5	20	5.8	9.6	52.0
3G0.5	20	6.1	14.0	64.0
4G0.5	20	6.6	19.0	72.0
5G0.5	20	7.3	24.0	88.0
7G0.5	20	7.9	34.0	130.0
8G0.5	20	8.8	38.4	145.0
9G0.5	20	9.4	43.2	180.0
12G0.5	20	10.6	58.0	196.0
18G0.5	20	12.7	86.0	260.0
25G0.5	20	15.0	120.0	368.0
34G 0.5	20	17.5	163.0	502.0
41G0.5	20	18.8	197.0	594.0
2×1	18	6.6	19.2	57.0
3G1	18	7.0	27.0	68.0
4G1	18	7.6	38.4	79.0
5G1	18	8.4	48.0	97.0
7G1	18	9.3	67.0	141.0
8G1	18	10.1	76.8	152.0
9G1	18	11.1	86.4	190.0
12G1	18	12.5	115.2	211.0
18G1	18	14.9	173.0	284.0
25G1	18	17.8	240.0	394.0
34G1	18	20.5	326.0	521.0
41G1	18	22.3	394.0	609.0
2×1.5	16	7.2	28.8	75.0
3G1.5	16	7.6	44.0	96.0
4G1.5	16	8.3	58.0	117.0
5G1.5	16	9.4	72.0	140.0
7G1.5	16	10.2	101.0	186.0
9G1.5	16	12.3	129.7	244.0
12G1.5	16	13.7	173.0	319.0
18G1.5	16	16.6	260.0	451.0
25G1.5	16	19.8	360.0	625.0
34G1.5	16	23.0	490.0	850.0
41G1.5	16	24.9	590.0	1041.0
2×2.5	14	8.0	48.0	115.0
3G2.5	14	8.5	72.0	143.0
4G2.5	14	9.5	96.0	185.0
5G2.5	14	10.6	120.0	221.0
7G2.5	14	11.6	168.0	293.0
