UL Approval Armoured Power Cable Teck Type Mv-105 or Mc-Hl Medium Voltage 5kv 100% Insulation Level

UL Approval Armoured Power Cable Teck Type Mv-105 or Mc-Hl Medium Voltage 5kv 100% Insulation Level image

Get Latest Price Request a quote

Product Details

Model NO.

MC-HL

Current

AC Cable

Insulation Material

Rubber

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Bare Copper Wire

Certification

ISO, CCC, CE, RoHS, UL

Model

Mc-Hl Cable

Brand

Huatong

Insulation

Epr XLPE

Jacket

Sunlight Resistant,Yellow PVC Jacket

Working Temperature

-40c--105c

Standard

UL1072 UL1569

Largest UL CSA Cable Manufacturer

Factory Price

Transport Package

Standard Export Drum

Specification

8awg 6awg 4awg 2awg 1awg--1000mcm

Trademark

Huatong

Origin

Tangshan, Hebei Province

HS Code

8544601290

Production Capacity

300km/Month

Packaging & Delivery

Package Size

28.00cm * 14.00cm * 28.00cm

Package Gross Weight

50.000kg

Product Description

UL Approval Armoured Power Cable Teck Type MV-105 or MC-HL Medium Voltage 5kV 100% Insulation Level

Application:
Type MC-HL cable are recommended as an economical altemate to a wire in conduit system. They are designed specffically for use as feeders or branch circuits in industrial and utillty
power distribution systems. They may be installed in both exposed and concealed work, wet and dry locations, directly buried in the earth, or embedded in concrete. They may be installed on metal racks, troughs, in cable trays or secured to supports not greater than 6 feet apart.

Structure:

Conductor: Uncoated copper compact stranded per ASTM B-496
Conductor screen:Extruded Semiconducting EPR
Insulation:EPR
Insulation screen:Extruded semiconducting EPR insulation screen
Shield:5mil uncoated copper tape helically applied with 12.5% nominal overlap
Binder Tap
Grounding Conductor: Three uncoated copper in accordance with UL 1072
Fillers:PP
Sheath:Close fitting, impervious, continuous, corugated aluminum
Jacket: sunlight resistant,yellow PVC jacket

Standard:
UL1072 UL1569

UL File No.:
E466020

Voltage:
5kV 133% Or 8kV 100%

Working temperature:
-40C–105C

Performance:
FT4 Flame retardant;
Oil resistant;
UV resistant.

Conductor Size(AWG/Kcmil)	No of Strands	Min. Average Insulation		Nom. Diam.Over Armor	Min. Jacket		Overall Diameter		Copper Grounding Conductor (AWG)	weight	Ampacity
		Thickness			Thickness		Thickness				In air	cable tray	Direct Burial
		mil	mm	Inches	mil	mm	inches	mm		lbs./1000′	A	A	A
6	7	115	2.92	1.37	50	1.27	1.48	37.6	3×10	1121	88	77	115
4	7	115	2.92	1.51	60	1.52	1.65	41.9	3×10	1418	115	100	150
2	7	115	2.92	1.64	60	1.52	1.78	45.2	3×10	1885	154	135	190
1	19	115	2.92	1.69	60	1.52	1.82	46.2	3×8	2156	180	155	215
1/0	19	115	2.92	1.78	60	1.52	1.91	48.5	3×8	2462	205	185	245
2/0	19	115	2.92	1.92	60	1.52	2.05	52.1	3×8	2907	240	210	280

Largest UL and CUL CSA Cable Manufacturer

Top 10 Cable manufactuer in China.
Largest Rubber cable manufacturer in China.
Leading ESP cable manufacturer.
Professional OEM manufacturer.
With UL,TUV,KEMA,CE,BV,PSB,SABS,MSHA,GL,NKK,KR,DNV,CCS certifications.
With TUV TYPE TESTING REPORT.

With ISO9001,ISO14001,ISO45001 syetem certifications.
ISO 17025 standard and CNAS approval laboratory.

2000+ employees, 2 factory in China .

Our Serivce:

1. 30years production experience and 22 years export experience .

2.Products certification :UL,CE,BV,TUV,KEMA,PSB,SABS,ABS,NK,LR,KR,GL etc

3. OEM service available based on official & legal authorization.

4.Strict quality control system.

5.Rapid delivery and feedback Faster lead time than our competitors.

6.Excellent quality with reasonable price.

7. Strong technical support (technical data, drawing, etc.)

8.Professional teamwork service for you actively.

9.Stock available, Free sample is available.

We are China UL Approval Armoured Power Cable Teck Type Mv-105 or Mc-Hl Medium Voltage 5kv 100% Insulation Level manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
