UL 1650 Certificate Icea S 75 381 2kv Type G Flexible Copper Epr Insulation CPE jacket 4 Core Power Conductor 4 Core Green Earth Conductor 2AWG Mining Cable

China UL 1650 Certificate Icea S 75 381 2kv Type G Flexible Copper Epr Insulation CPE jacket 4 Core Power Conductor 4 Core Green Earth Conductor 2AWG Mining Cable manufacture and supplier

UL 1650 Certificate Icea S 75 381 2kv Type G Flexible Copper Epr Insulation CPE jacket 4 Core Power Conductor 4 Core Green Earth Conductor 2AWG Mining Cable image

Get Latest Price Request a quote

Product Details

Model NO.

type g cable

Current

DC & AC

Insulation Material

Rubber

Sheath Material

Rubber

Material Shape

Round Wire

Wire Core Material

Bare Copper Wire

Certification

ISO, CCC, CE

Model

Type W G G-Gc

Brand

Rneda

Core

2 Core, 3 Core, 4 Core, 5 Core

Insulation and Sheath

Rubber

Copper

Flexible

Size

6AWG-500kcmil

Cable

Type W G G-Gc

Packing Type

Flexible Roll or Wooden Drum

Certificate

UL Msha

Factory

Chinese Largest Rubber Cable Manufacturer

Price

Direct Factory Price

Characteristics

Oil Resistance

Sheath

CPE, Pcp, Cr

Conductor

Tinned Copper

Transport Package

Wooden & Steel Drum

Specification

IEC DIN ASTM VDE BS

Trademark

RNEDA

Origin

China

HS Code

8544492100

Production Capacity

1000km Per Month

Packaging & Delivery

Package Size

20.00cm * 20.00cm * 20.00cm

Package Gross Weight

1.000kg

Product Description

TOP TEN CABLE MANUFACTURER/EXPORTER IN CHINA
LARGEST CABLE MANUFACTUER IN NORTH CHINA
ANNUAL EXPORT VOLUME EXCEED 200MILLION USD
WITH UL,TUV,KEMA,CE,BV,PSB,SABS,LLOYD’S,GL,NK,KR,ABS PRODUCTS CERTIFICATIONS
WITH TUV TYPE TESTING REPORT
WIDE PRODUCTS RANGE
ISO9001,ISO18001,OHSAS18001 SYSTEM CERTIFICATIONS
CNAS APPROVAL LABORATORY

Application:
Use on AC off track equipment such as miners, shuttle cars, cutting machines, drills, conveyors and pumps. Power to open pit strip and deep mines. For applications requiring ground check for added safety. Other industrial applications.

Structure:
1. Conductors:Annealed flexible stranded tin copper
2. Separator:Tape separator between conductor and insulation
3. Insulation:Ethylene-propylene rubber (EPR) Color black/white/red/orange
4. Grounding conductors:Annealed flexible stranded tin copper, green/green/green/green EPR insulation
5. Assembly:Power and grounds cores cabled together to form a round core
6. Filler:rubber filled binder tape over core.
7. Jacket:Black heavy duty CPE thermosetting compound.

Standard:
UL listed
MSHA listed

UL File No.:
E482608

Voltage:
2000V

Performance:
Oil resistant;
UV resistant.

Technical data:

Phase conductor no. x cross section	Phase conductor stranding	Grounding wire no. x section	Nom. insulation thick.	Approx. diam.	Approx. weight	Ampacity (90ºC conductor and 30ºC ambient temp.)
(awg/mcm)	(no.)	(awg)	(mm)	(mm)	(kg/km)	(A)
4×8	133	4×12	1.52	24.9	1010	52
4×6	259	4×12	1.52	28	1325	70
4×4	259	4×10	1.52	30.9	1825	91
4×3	259	4×10	1.52	32.8	2115	106
4×2	259	4×9	1.52	36.5	2650	122
4×1	259	4×8	2.03	40.4	3250	142
4×1/0	266	4×7	2.03	43.3	3885	164
