Type61A Type61 Ecc Portable Sans1520-1 Fire Resistance Mineral Power Rubber Cable Mining

Type61A Type61 Ecc Portable Sans1520-1 Fire Resistance Mineral Power Rubber Cable Mining image

Get Latest Price Request a quote

Product Details

Model NO.

Mining cable

Current

AC Cable

Insulation Material

Epr/EPDM

Sheath Material

CPE/Cr

Material Shape

Round Wire

Wire Core Material

Tinned Wire

Certification

ISO, CCC, CE, RoHS, VDE

Model

Type61A Type61 Ecc

Brand

Hebei Huatong Cables

Product Name

Mining Cable/Trailing Cable

Certificate

CE, ISO9001, ISO14001, Oashs18001, UL

Standard

Sans 1520-1

Sheath

CPE/Cr

Rated Voltage

640/1100V

Insulation

EPDM/Epr

Cross Section

10-240mm2

Number of Cores

3+3

Price

Direct Factory Price

Transport Package

Standard Export Drums

Specification

SANS1520-1

Trademark

Hebei Huatong Cables

Origin

Hebei, China

HS Code

8544492100

Production Capacity

1000000meter Per Month

Product Description

Type61 640/1100V Rubber Power Cable Tinned Copper Conductor Epr Insulation CPE Sheath Mining Cable

LARGEST CABLE MANUFACTUER IN NORTH CHINA

ANNUAL EXPORT VOLUME EXCEED 200MILLION USD

WITH UL,TUV,KEMA,CE,BV,PSB,SABS,LLOYD’S,GL,NK,KR,ABS PRODUCTS CERTIFICATIONS

WITH TUV TYPE TESTING REPORT

WIDE PRODUCTS RANGE

ISO9001,ISO18001,OHSAS18001 SYSTEM CERTIFICATIONS

CNAS APPROVAL LABROTARY

Applications:

Submersible pumps , on board wiring for machines .

Single , double ,triple drilling rigs ,loaders , low haulage dumpers , loaders , large drilling rigs.

Other industrial applications

Specifications:

Conductors Flexible class 5,inned annealed copper wires

Separator A suitable tape separator between the conductor and insulation.

Insulation Ethylene propylene thermosetting compound

Core of cable Three tinned copper braid screened power cores and two unscreened pilot core and one tinned earth

conductor laid up in the right hand lay around rubber dummy centre

Outer sheath Extra heavy duty yellow CPE sheath,Yellow.

Features

Excellent flexibility

Min. ambient temperature -25 oC , max. conductor temperature 90oC

Marking for easy identification

UV ,sunlight , ozone ,oil, resistant

Technical data

Physical Properties
Power cores
Conductor sizes (mm²)	16	25	35	50	70	95	120	150
Maximum wire diameter ( mm)	0.41	0.41	0.41	0.51	0.51	0.51	0.51	0.51
Approx. conductor diameter ( mm)	5.3	6.8	8.5	10.3	11.9	13.5	15.5	17.3
Maximum screen wire diameter (mm)	0.31	0.31	0.31	0.31	0.31	0.31	0.31	0.31
Braided screen filling factor (%)	80	80	80	80	80	80	80	80
Approx. summarized screen cross-section for power cores (weighing method) (mm²)	22	25	27	32	37	43	47	52
Pilot cores
Conductor sizes ( mm²)	10	10	16	16	16	16	16	16
Maximum wire diameter ( mm)	0.41	0.41	0.41	0.41	0.41	0.41	0.41	0.41
Approx. conductor diameter ( mm)	4.2	4.2	5.3	5.3	5.3	5.3	5.3	5.3
Lay Ratio (maximum) (x PCD)	8	8	8	8	8	8	8	8
Cable diameter
Approx. (mm)	31	38	43	47	52	58	63	70
Cable mass (approx.) (kg/m)	1.8	3.1	3.6	4.5	5.6	7.0	8.4	10.2
Minimum bending radius (mm)	200	240	260	290	320	350	390	430
Maximum recommended tension (kN)	0.7	1.1	1.6	2.3	3.2	4.3	5.4	6.8
