Type W UL1650 RoHS 90c 2000 V 6AWG 5c Rubber Portable Power Cable

UL1650  TYPE W 90°C, 2000 V (UL/CSA)  TYPE W PORTABLE POWER CORD  UL/CUL  NO. E482608

Conductor:

• Stranded bare copper, fully annealed

Insulation:

• Premium-grade, color-coded EPDM 90°C

Jacket:

• Chlorinated Polyethylene (CPE) 90°C, black

Applications:

• Industrial and light- to medium-duty mining

• Heavy-duty service as power supply cable

• AC systems (grounded and ungrounded)

• Mobile and portable electrical equipment

• Motor and battery leads

• 2-conductor cables- use on DC or AC single-phase systems where grounding is not required

• 3-conductor cables- use on AC systems where no grounding is required, or on DC systems with one conductor for grounding

• 4-conductor cables- use on two- or threephase AC systems with one conductor used for grounding

• 5-conductor cables- use in applications where separating the system neutral from the frame ground is required

Standards:

• UL Type W • CSA • MSHA approved • UL Type RHH/RHW 600 Volt (Single conductor only) • RoHS compliant

Features:

•Withstands severe environmental conditions and exposure to oil, acid, alkalies, heat, moisture, and most chemicals

•Water and sunlight resistant; also meets or exceeds flame test requirements of MSHA and UL (single conductor only).

•Rope lay stranding for maximum flex life

•Excellent impact resistance

•Cable core bound for superior flexibility and toughness

•Temperature range: -40°C to +90°C

COLOR CODE CHART

COND

Type W 4 & 5 Conductors 90°C 600/2000V

APPLICATION:

Type W is for use in heavy duty power systems as power supply cable such as: AC systems (grounded and ungrounded); mobile and portable electrical equipment; motor and battery leads. 4 conductor constructions are for three phase systems with one conductor being used as a ground. 5 conductor constructions are for three phase systems where one conductor is used as a neutral and one conductor being used as a ground, Type W is for applications up to 2000 volts and temperatures from -40°C to +90°C.

CONDUCTORS: • Flexible strand soft drawn tin coated copper conductor • Green conductor for grounding conductor purpose only

SEPARATOR: • Tape separator between conductor and insulation

INSULATION: • Ethylene-Propylene Rubber (EPR)

REINFORCEMENT: • Single faced rubber filled binder tape applied over core

JACKET: • Black heavy duty CPE thermoset compound. Ozone, sunlight, oil, flame, weather, impact, and abrasion resistant

COLOR CODE:  Circuit Identification Color :

STANDARDS:

• UL 44 Thermoset-Insulated Wire and Cable

• UL 1650 Portable Power Cable

• CSA C22.2 96-17 • C(UL) FT1 & FT5

• Oil Resistant Oil Resistant Inners, Sunlight resistant 90°C Wet or Dry

• ASTM B-33 Tin-Coated Soft or Annealed Copper Wire for Electrical Purposes

• Rated and flexible at -40°C to +90°C

• ASTM B-172 Rope-Lay-Stranded Copper Conductors Having Bunch-Stranded Members

• ICEA S-75-381/NEMA WC 58 Portable and Power Feeder Cables for Use in Mines and Similar Applications

• ICEA S-95-658/NEMA WC 70 Nonshielded Power Cables Rated 2000 Volts or Less
