Portable Power Cable

Type W Portable Power Cable

90°C, 600/2000 Volt

 Construction:


    Conductor: 8 AWG through 500 kcmil fully annealed stranded Bare Copper

    Insulation: Premium-grade Ethylene Propylene Diene Monomer Rubber (EPDM)

    Jacket: Black

    Cable Reinforcement: An open polyester braid reinforcement is applied between the insulation and jacket for mechanical strength.

Temperature Range: -40°C to +90°C

 Voltage Rating:

        600 volts Type RHH/RHW

        2000 volts Type W

  Applications:


    Type W portable power cable is designed for use in portable power systems and entertainment industry activities such as theatre, television, night clubs, motion pictures, mobile communications vans, spotlights, sound systems and any similar applications that would require permanent or temporary power. Type W cable is also suitable for use in permanent wiring of 600 volt power supplies, hoists, cranes and other applications where flexible power leads must be installed in conduit or raceways.

 Industry Approvals:

    UL Type W

    UL Type RHH or RHW

    MSHA Approved

    RoHS Compliant

 Features:

    Water-resistant

    Sunlight-resistant

    Designed to withstand severe environmental conditions

    Withstands exposure to oil, acids, alkalies, heat, flame, moisture and chemicals

    Meets or exceeds flame test requirements of MSHA and UL
