Type of Mhf Cable with Aluminum Alloy Conductors XLPE Insulattion

Type of Mhf Cable with Aluminum Alloy Conductors XLPE Insulattion image

Get Latest Price Request a quote

Product Details

Model NO.

MHF

Application

Heating, Building

Conductor Material

AA-8000 Series Aluminum Alloy

Sheath Material

XLPE

Insulation Material

Sunlight Resistant XLPE

Material Shape

Round Wire

Range of Application

Conduit or Recognized Raceways for Services

Certification

ISO9001, CE, CCC, RoHS, VDE

Brand

Huatong

Voltage

600V

Transport Package

Coils and Drums

Specification

6AWG TO 1000MCM

Trademark

Renda

Origin

China

HS Code

8544492100

Production Capacity

200000m/Month

Product Description

4/0-4/0-4/0-2/0 Aluminum Mobile Home Feeder Service Entrance Cable

Product Description

The MHF mobile home Feeder is 600 voltage aluminum alloy conductors, cross-linked polyethylene (XLPE) insulated moisture, heat, low-temp,sunlight resistant, flame retardant cable wire.

Applications

Mobile Home Feeder Cable is used to provide power from the electrical disconnect to the distribution panel board in mobilehome applications accordance with the requirements of the NEC NFPA 70, 2011 Edition, suitable for direct burial at conductor temperatures not to exceed 90°C. Voltage rating is 600 volts.

Standards

Mobile home feeder meets the requirements

• ASTM B800 and B801

• UL 44

• UL 854 (USE-2)

• ICEA T-29-520

Construction

HUATONG TYPES mobile home feeder consists of four quadruplexed type RHH or RHW-2 or USE-2 AA-8000 series aluminum alloy compacted

conductors. The cable contains 2 triple-extruded phase conductors, a white striped neutral conductor and a green grounding conductor to

eliminate the need for field marking per the National Electrical Code. The insulation is sunlight resistant.

Technical Parameter List

Size (AWG)	Phase Conductor		Neutral Conductor		Grounding Conductor		Overall Cable O.D. (Mils)	Weight Per 1000′ (Lbs)	Ampacity
Size (AWG)	Strand	Diameter (Mils)	Strand	Diameter (Mils)	Strand	Diameter (Mils)	Overall Cable O.D. (Mils)	Weight Per 1000′ (Lbs)	Ampacity
2-2-4-6	6	388	7	33	6	292	937	301	100
2-2-2-4	6	388	6	333	4	333	937	345	100
2/0-2/0-1-4	18	536	18	459	7	333	1294	553	150
2/0-2/0-2/0-1	18	536	18	536	8	462	1294	671	150
4/0-4/0-2/0-4	18	635	18	536	7	333	1533	784	200
4/0-4/0-4/0-2/0	18	635	18	635	18	536	1533	989	200

We are China Type of Mhf Cable with Aluminum Alloy Conductors XLPE Insulattion manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
