Product Details

Model NO.

type 209, type 210

Application

Mine

Conductor Material

Copper

Sheath Material

Pcp

Insulation Material

Rubber

Material Shape

Round Wire

Range of Application

Mine

Certification

ISO9001, CE, CCC, RoHS, VDE

Brand

QIFAN

Color of Insulation

as Per Requirements

Armour

Screen

Yes

Leadtime

15days

Transport Package

Drums or Customized

Specification

as per requirements

Trademark

Qifan

Origin

China

HS Code

8544492100

Production Capacity

1000000000 Meters Per Year

Product Description

Type 209 Flexible Copper Screened Mining Cable

APPLICATION
For use as flexible feeder cable to machinery. More suitable as
a trailing cable. Smaller sizes used for drills, held hand tools
and equipment. Other industrial applications.

CHARACTERISTICS

Voltage Rating Type 209.1 – 1.1kV Type 209.3 – 3.3kV Type 209.6 – 6.6kV Type 209.11 – 11kV

Temperature Rating -25 oC to +90 oC

CONSTRUCTION

Conductor: Tinned annealed copper wires
Separator/Screen: 1.1kV: Paper separator Other voltages semi-conductive thermosetting compound
Insulation: EPR (Ethylene Propylene Rubber) type R-EP-90
Insulation Screen: 1.1kV: Synthetic tape From 3.3kV: Semi-conductive thermosetting compound
Screen: Tinned copper/polyamide braid
Central Pilot Core: EPR covered flexible stranded Tinned Copper
Cable Assembly: Three screened power laid up with right hand direction on cradle separator with central pilot core
Cradle Separator: Semi-conductive thermosetting compound
Sheath: PCP (Polychloroprene) thermosetting compound HD-85-PCP – extra heavy duty, oil resistance and flame retardant Sheath Colour: Black

STANDARDS

AS/NZS 1802:2003, AS/NZS 1125:2001, Water resistant Flame retardant, UV, sunlight, ozone and oil resistant
