Type 201 and 211 Mining Cable Flexible Trailing Cable with Galvanised Steel Pliable Wire Armouring 640/1100V

Type 201 and 211 Mining Cable Flexible Trailing Cable with Galvanised Steel Pliable Wire Armouring 640/1100V image

Get Latest Price Request a quote

Product Details

Model NO.

type 201, type 211

Application

Mine

Conductor Material

Copper

Sheath Material

Pcp

Insulation Material

Rubber

Material Shape

Round Wire

Range of Application

Mine

Certification

ISO9001, CE, CCC, RoHS, VDE

Brand

QIFAN

Color of Insulation

as Per Requirements

Armour

Yes

Screen

Yes

Leadtime

15days

Transport Package

Drums or Customized

Specification

as per requirements

Trademark

Qifan

Origin

China

HS Code

8544492100

Product Description

Type 201 and 211 Flexible Trailing Cables with Galvanised Steel Pliable Wire Armouring

640/1100 volt in accordance with BS 6708:1998 For use as mine roadway extension cables and mechanically protected trailing cables in quarries and coalface lighting. BCS 504 refers.

Description
Type 211
3 off flexible tinned annealed copper (TAC) conductors, MEPR insulated and copper/nylon screened, plus 1 unscreened earth core, laid up around a PCP centre, elastomeric bedding, pliable galvanised steel wire armoured and sheathed overall with a heavy duty flame retardant elastomeric compound.

Type 201
3 off flexible tinned annealed copper (TAC) conductors, MEPR insulated and copper/nylon screened, laid up around a PCP cradle centre, elastomeric bedding, pliable galvanised steel wire armoured and sheathed overall with a heavy duty flame retardant elastomeric compound.

Type 201, 211Flexible Trailing Cables To BS 6708:1998

Nominal Cross-sectional Area of Conductor (Sq.mm)	Max. Resistance of Class 2 Conductor at 20ºC (Ω/km)
Nominal Cross-sectional Area of Conductor (Sq.mm)	Copper Conductor	Aluminum Conductor
0.5	36.0
0.75	24.5
1	18.1
1.5	12.1
2.5	7.41
4	4.61	7.41
6	3.08	4.61
10	1.83	3.08
16	1.15	1.91
25	0.727	1.20
35	0.524	0.868
50	0.387	0.641
70	0.268	0.443
95	0.193	0.320
120	0.153	0.253
150	0.124	0.206
185	0.0991	0.164
240	0.0754	0.125
300	0.0601	0.100
400	0.0470	0.0778
500	0.0366	0.0605
630	0.0283	0.0469
800	0.0221	0.0367

We are China Type 201 and 211 Mining Cable Flexible Trailing Cable with Galvanised Steel Pliable Wire Armouring 640/1100V manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
