Thhn 350 Mcm T90 Mtw 300mcm Power Building Electric Wire and Cable Supplies

Thhn 350 Mcm T90 Mtw 300mcm Power Building Electric Wire and Cable Supplies image

Get Latest Price Request a quote

Product Details

Model NO.

thhn

Application

Building

Conductor Material

Copper

Sheath Material

Nylon

Insulation Material

PVC

Material Shape

Round Wire

Range of Application

House

Certification

ISO9001, UL

Brand

Rneda

Color

as Requirement

Flame Retartant

VW-1

Oil Resistant

Yes

Unti-UV

Transport Package

Roll or Drum

Specification

250MCM

Trademark

HT cables

Origin

China

HS Code

8544492100

Production Capacity

1000km/Month

Product Description

UL THHN THW THWN THWN-2

Type THHN/THWN conductors are primarily used in conduit for services, feeder, and branch

circuits in commercial or industrial applications as specified in the National Electrical Code.

When used as type THHN, conductor is suitable for use in dry locations at temperatures not to

exceed 90°C.

When used as type THWN, conductor is suitable for use at temperatures not to exceed 90 ° C, dry

locations or 75 ° C wet locations or not to exceed 75°C when exposed to oil or coolant.

When used as type THWN-2, conductor is suitable for use in wet and dry locations at

temperatures not to exceed 90°C or not to exceed 75°C when exposed to oil or coolant.

Structure:

1. Conductor: soft plain copper, conforms to ASTM B3, B8

2. Insulation: PVC, color can be black, red, blue, green, white, purple, orange, etc

3. Jacket: Nylon

Standard:UL83

UL File No.: E468871

Voltage:600V

Working temperature:

in dry locations only at temperature not to exceed 90°C.

Printing:

HT CABLES (UL) E468871 Type THHN/THWN/THWN-2 *AWG 600V 90C DRY OR WET SUN

RES 2023 ****FT

Colour:

1-Black 2-White 3-Red 4-Blue 5-Green 6-Yellow 7-Orange 8-Brown 9-Grey 10-Pink

11-Purple 12-Tan

Technical data:

Size AWG /Kcmil	Number of strands (Nos)	Min. Average Insulation		Min. Jacket		Overall	Approx. Wt. lbs/1000ft
		Thickness		Thickness		Diameter
		mil	mm	mil	mm	mm
14	1	15	0.38	4	0.1	2.8	15
12	1	15	0.38	4	0.1	3.3	23
10	1	20	0.51	4	0.1	4.2	37
14	19	15	0.38	4	0.1	2.8	17
12	19	15	0.38	4	0.1	3.3	25
10	19	20	0.51	4	0.1	4.2	39
8	19	30	0.76	5	0.13	5.5	64
6	19	30	0.76	5	0.13	6.5	96
4	19	40	1.02	6	0.15	8.2	154
3	19	40	1.02	6	0.15	8.9	190
2	19	40	1.02	6	0.15	9.8	235
1	19	50	1.27	7	0.18	11.3	301
1/0	19	50	1.27	7	0.18	12.4	372
2/0	19	50	1.27	7	0.18	13.5	461
3/0	19	50	1.27	7	0.18	14.8	572
4/0	19	50	1.27	7	0.18	16.3	710
250	37	60	1.52	8	0.2	18.0	851
300	37	60	1.52	8	0.2	19.4	1008
350	37	60	1.52	8	0.2	20.7	1165
400	37	60	1.52	8	0.2	21.9	1327
450	37	60	1.52	8	0.2	23.1	1482
500	37	60	1.52	8	0.2	24.1	1637
550	37	70	1.78	9	0.23	25.7	1822
600	61	70	1.78	9	0.23	26.7	1977
650	61	70	1.78	9	0.23	27.6	2133
700	61	70	1.78	9	0.23	28.5	2294
750	61	70	1.78	9	0.23	29.4	2449
800	61	70	1.78	9	0.23	30.2	2603
900	61	70	1.78	9	0.23	31.8	2919
1000	61	70	1.78	9	0.23	33.3	3233

We are China Thhn 350 Mcm T90 Mtw 300mcm Power Building Electric Wire and Cable Supplies manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
