Tfl Cable Communication Multi Core Copper Cable Flame Retardant Polyolefin Insulation Cable

China Tfl Cable Communication Multi Core Copper Cable Flame Retardant Polyolefin Insulation Cable  manufacture and supplier

Tfl Cable Communication Multi Core Copper Cable Flame Retardant Polyolefin Insulation Cable image

Get Latest Price Request a quote

You May Like

Product Details

Current
DC Cable
Insulation Material
PE
Sheath Material
Crosslinking
Material Shape
Flat Wire
Wire Core Material
Tinned Wire
Certification
ISO
Model
Tfl Cable
Brand
Ren Da
Sizes
2.5mm2 6mm2 10mm2 16mm2 25mm2
Cores
2 Core
Insulation
Flame Retardant Polyolefin Black and Grey.
Sheathed
Flame Retardant Polyolefin, Grey or Black
Conductor
Tinned Copper Wire
Shield
Aluminum Polyester Shield 100% Coverage
Transport Package
Plywoodn Drum
Specification
2.5mm2 6mm2 10mm2 16mm2 25mm2
Trademark
RNE DA
Origin
Tangshan, Hebei Province
HS Code
8544492100
Production Capacity
100km/Month

Product Description

600V Outdoor Black Sheath 4G 5G DC 2x16mm2 (2x6AWG) Telecommunication Equipment Low Smoke Halogen Free TFL Power Cable with UL certificate

Telecommunication Central Office Power Cable Rated 75 or 90ºC dry, optionally 60, 75 or 90 ºC wet,600V


Application



Halogen free, flexible connecting cable for fixed installation. Intended for power supply of telecom equipment, where there are requirements for low inductance and good temperature resistance. Grey jacket for indoor use. Black jacket is sunlight resistant, UV stabilized, for outdoor use.

Structure

Conductor
Stranded, tinned, annealed copper, IEC 60228 class 5. Three parallel cores to form a flat conductor.

Insulation
Flame retardant polyolefin black and grey.

Shield
Inner: aluminum polyester shield 100% coverage
Outer: Tinned copper Clad aluminum or tinned copper wire braid

Sheath
Flame retardant polyolefin , grey or black

Operating voltage: Max. 90 ºC,dry

Fire resistance IEC 60332-3 cat C UL 1685, Vertical tray


Standards

UL2731, Telecommunication Central Office Power, Battery, and Distribution Cables


Product Parameters
