Tc-Er AWG12 600V UL1277 Control Tray XLPE Power Cable with UL Listed

Tc-Er AWG12 600V UL1277 Control Tray XLPE Power Cable with UL Listed image

Get Latest Price Request a quote

Product Details

Model NO.

Application

Heating

Sheath Material

PVC

Insulation Material

PVC/XLPE

Material Shape

Round Wire

Range of Application

Power and Control Tray

Certification

ISO9001, CCC, RoHS, UL

Brand

UL cUL

Voltage

Low Voltage 600V

Package

Rolls/Reels

Used

Industrial Power or Control Circuits

Color

White/Blue/Red/Black/Brown/Yellow etc

Transport Package

Coils and Drums

Specification

12AWG to 2000KCMIL

Trademark

Renda

Origin

China

HS Code

8544492100

Production Capacity

200000m/Month

Product Description

XHHW-2/PVC Circuit | Tray Cable TCP Cable with UL Certification for USA

Application:
In free air, raceways or direct burial
In wet or dry locations
Permitted for use in Class I, Division 2 industrial hazardous locations per NEC
Permitted for Exposed Run (ER) use in accordance with NEC

Standard

UL 1277

Cable Construction

Conductor: 14 AWG thru 750 kcmil bare, annealed copper per ASTM B3 Class B stranding per ASTM B8
Insulation: Flame-retardant Cross-linked Polyethylene (XLPE) Color-coded per ICEA Method 4; individual conductors colored black with conductor number surface printed in contrasting ink
Ground: Uninsulated bare annealed copper per ASTM B3 Class B stranding per ASTM B8
Jacket: Lead-free, flame-retardant, sunlight-resistant Polyvinyl Chloride (PVC)

Cable Parameters

Type	Number of Conductors /size			PVC insulated	Jacket Thickness	Overall Diameter	Approximate Weight
Type	n	*	AWG	mm	mm	mm	kg/km
TC-THHN	2	*	14AWG	0.38	1.14	8.5	102
TC-THHN	3	*	14AWG	0.38	1.14	9.0	130
TC-THHN	4	*	14AWG	0.38	1.14	9.7	161
TC-THHN	5	*	14AWG	0.38	1.14	10.5	193
TC-THHN	6	*	14AWG	0.38	1.14	11.3	226
TC-THHN	7	*	14AWG	0.38	1.14	11.3	249
TC-THHN	9	*	14AWG	0.38	1.52	14.9	360
TC-THHN	10	*	14AWG	0.38	1.52	14.9	382
TC-THHN	12	*	14AWG	0.38	1.52	15.4	435
TC-THHN	15	*	14AWG	0.38	1.52	16.9	530
TC-THHN	16	*	14AWG	0.38	1.52	16.9	553
TC-THHN	19	*	14AWG	0.38	1.52	17.7	636
TC-THHN	20	*	14AWG	0.38	1.52	18.7	677
TC-THHN	25	*	14AWG	0.38	1.52	20.6	829
TC-THHN	30	*	14AWG	0.38	2.03	22.7	1020
TC-THHN	37	*	14AWG	0.38	2.03	24.4	1219

We are China Tc-Er AWG12 600V UL1277 Control Tray XLPE Power Cable with UL Listed manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
