T90 Nylon/Twn75 600 Volts 90° C Copper Wire cUL Certificate for Building Wire

T90 Nylon/Twn75 600 Volts 90° C Copper Wire cUL Certificate for Building Wire image

Get Latest Price Request a quote

Product Details

Model NO.

T90 Wire

Application

Indoor, Construction, Building

Conductor Material

Copper

Sheath Material

PVC

Insulation Material

PVC

Material Shape

Flat Wire

Range of Application

Indoor, Construction, Building

Certification

ISO9001, CE, CCC, RoHS, cUL Certificate

Brand

Rneda

Voltage

300V

Standard.

cUL719

Product Name

Nmd90

Conductor

Copper

Insulation

PVC

Sheath

PVC

Color

Yellow, White

Size

14/2

Temperature Range

-40 Degrees F - 194 Degrees F

Market

Canada

Transport Package

Soft Packing, or as Your Request

Specification

14/2 awg

Trademark

Hebei Huatong Cables

Origin

China. Hebei. Tangshan

HS Code

8544492100

Production Capacity

5000km Per Month

Product Description

T90 Nylon/TWN75 600 Volts 90°C Copper Wire CUL Certificate for Building Wire

TOP TEN CABLE MANUFACTURER IN CHINA
LARGEST CABLE MANUFACTUER IN NORTH CHINA
ANNUAL EXPORT VOLUME EXCEED 200MILLION USD
WITH UL,TUV,KEMA,CE,BV,PSB,SABS,LLOYD’S,GL,NK,KR,ABS PRODUCTS CERTIFICATIONS
WITH TUV TYPE TESTING REPORT
WIDE PRODUCTS RANGE
ISO9001,ISO18001,OHSAS18001 SYSTEM CERTIFICATIONS
CNAS APPROVAL LABROTARY

1. Application:

T90 is intended for general purpose applications as defined by the NEC. Permitted appropriate use at temperatures not to exceed 90°C or not to exceed 75°C in oil or coolant and for new construction or rewiring for 600-volt applications. Pulling heads are available on sizes 8 AWG and larger.

2. Construction:

Conductor: Annealed Copper, solid or stranded sizes 14AWG up to 1000MCM

Insulation: Premium Grade Flame Retardant Polyvinyl Chloride( PVC)

Jacket: Tough Polyamide (Nylon)

3. Standard&Test Specification:

ASTM B3, B8 and B787

Built to C.S.A C22.2 No.75

-25°C Cold Bend Test Compliant

Canadian Electrical Code • CSA FT-1 – Flame Test

UL, c(UL) listed

Specification:

T90 Packing picture

Conductor		Insulation Thickness	Jacket Thickness	Cable Dimensions	Approx. Weight
Size (AWG or kcmil)	# of Strands	mm	mm	mm	kg/km
14	1	0.38	0.1	2.59	23
12	1	0.38	0.1	3.02	34
10	1	0.51	0.1	3.81	55
14	19	0.38	0.1	2.77	23
12	19	0.38	0.1	3.25	36
10	19	0.51	0.1	4.09	57
8	19	0.76	0.13	5.41	93
6	19	0.76	0.13	6.32	141
4	19	1.02	0.15	8.08	227
3	19	1.02	0.15	8.79	281
2	19	1.02	0.15	9.6	349
1	19	1.27	0.18	11	446
1/0	19	1.27	0.18	12	553
2/0	19	1.27	0.18	13.2	687
3/0	19	1.27	0.18	14.4	856
4/0	19	1.27	0.18	15.8	1068
250	37	1.52	0.2	17.6	1266
300	37	1.52	0.2	18.9	1506
350	37	1.52	0.2	20.2	1747
400	37	1.52	0.2	21.4	1985
500	37	1.52	0.2	23.5	2462
600	61	1.78	0.23	26	2957
750	61	1.78	0.23	28.6	3667
1000	61	1.78	0.23	32.4	4847

Other cables we can offer in the North American market:

1. Service entrance cable

2. SEU/SER/SE

3. XHHW/RHW/RHH

4. MV 90/105 URD

5. THW/THHN/THWN

6. MC/AC/AC90/TECK series cables

7. Portable power cable( type SOOW, G, G-GC, SHD-GC)

8. welding cable

9. photo voltaic(PV) wire

10. diesel locomotive cable

11. power and control tray cable

12. bus drop cable

13. DG cable

14. shipboard cable

15. telecommunication cables

16. AC cables

17. AWM cables

We are China T90 Nylon/Twn75 600 Volts 90° C Copper Wire cUL Certificate for Building Wire manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
