Sy LSZH Control Flexible Cable

Sy LSZH Control Flexible Cable image

Get Latest Price Request a quote

Product Details

Model NO.

Application

Heating, Industrial

Conductor Material

Copper

Sheath Material

LSZH

Insulation Material

LSZH

Material Shape

Round Wire

Range of Application

Flame Retardant

Certification

ISO9001, CE, CCC, VDE

Brand

Huadong

Rated Voltage

300/500V

Amour

Non Armour

Core

2-48 Cores or Customized

Standard

IEC/En 60332-1-2,IEC/En 60332-3-24

Sample

Available

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

SY LSZH Control Flexible Cable

Application
Used as interconnecting cable for measuring, controlling or regulation in control equipment for assembly and production lines, conveyors and for computer units. Suitable for flexible use in conditions of light mechanical stress. Can be used outdoors when protected against direct sunlight, and in dry or moist conditions indoors. The braided screen offers mechanical protection and a level of electro-magnetic shielding. The galvanized coating helps protect against corrosion. For installations where fire, smoke emissions and toxic fumes create a potential risk to life and equipment.
Construction
Conductor Class 5 flexible copper conductor
Insulation LSZH (Low Smoke Zero Halogen) Type TI6
Bedding LSZH (Low Smoke Zero Halogen) Type TM7
Braiding GSWB (Galvanized Steel Wire Braid) minimum coverage of braiding shall be 50%
Sheath LSZH (Low Smoke Zero Halogen) Type TM7

Characteristics
Voltage Rating (Uo/U) 300/500V
Temperature Rating -15ºC to +70°C
Minimum Bending Radius 10 x overall diameter

Standard
Flame Retardant according to IEC/EN 60332-1-2,IEC/EN 60332-3-24 Low Smoke Zero Halogen according to IEC/EN 61034-1 Determination of halogen acid gas content: IEC/EN 60574-1 Determination of acidity and conductivity: IEC/EN 60574-2

Cable Parameter:

NO OF CORES	NOMINAL CROSS SECTIONAL AREA mm2	NOMINAL OVERALL DIAMETER mm	NOMINAL WEIGHT kg/km
2	0.14	3.2	12
2	0.25	3.6	17
2	0.34	4.2	19
2	0.50	5.6	23
2	0.75	5.9	48
2	1	6	61
3	0.14	3.4	17
3	0.25	3.8	21
3	0.34	4.5	19
3	0.51	5.9	31
3	0.75	6	57
4	0.14	3.7	19
4	0.25	4.1	27
4	0.34	4.9	32
4	0.5	6.4	39
4	0.75	6.5	69
4	1	6.5	85
5	0.14	4	22
5	0.25	4.5	32
5	0.34	5.6	38
5	0.5	7	47
7	0.14	4.7	27
7	0.25	5.4	42
7	0.34	6.6	50
7	0.5	7.6	65
8	0.14	5.31	30
8	0.25	6.1	51
8	0.34	7.2	61
8	0.5	7.9	75
12	0.14	5.8	48
12	0.25	6.6	71
12	0.34	7.9	85
12	0.5	9.7	121
