Supplier of African Market Mining Power Usage Rubber Sheathed Flexible Epr/CPE Oil Resistance Coal Mine Type 61 Ecc 25mm2 35mm2 Trailing Cable

China Supplier of African Market Mining Power Usage Rubber Sheathed Flexible Epr/CPE Oil Resistance Coal Mine Type 61 Ecc 25mm2 35mm2 Trailing Cable manufacture and supplier

Supplier of African Market Mining Power Usage Rubber Sheathed Flexible Epr/CPE Oil Resistance Coal Mine Type 61 Ecc 25mm2 35mm2 Trailing Cable image

Get Latest Price Request a quote

Product Details

Model NO.

Trailing Cable

Current

DC & AC

Insulation Material

Rubber

Sheath Material

Rubber

Material Shape

Round Wire

Wire Core Material

Bare Copper Wire

Certification

ISO, CCC, CE

Model

Type W G G-Gc

Brand

Rneda

Core

2 Core, 3 Core, 4 Core, 5 Core

Insulation and Sheath

Rubber

Copper

Flexible

Size

6AWG-500kcmil

Cable

Type W G G-Gc

Packing Type

Flexible Roll or Wooden Drum

Certificate

UL Msha

Factory

Chinese Largest Rubber Cable Manufacturer

Price

Direct Factory Price

Characteristics

Oil Resistance

Sheath

CPE, Pcp, Cr

Conductor

Tinned Copper

Transport Package

Wooden & Steel Drum

Specification

IEC DIN ASTM VDE BS

Trademark

RNEDA

Origin

China

HS Code

8544492100

Production Capacity

1000km Per Month

Product Description

TOP TEN CABLE MANUFACTURER/EXPORTER IN CHINA
LARGEST CABLE MANUFACTUER IN NORTH CHINA
ANNUAL EXPORT VOLUME EXCEED 200MILLION USD
WITH UL,TUV,KEMA,CE,BV,PSB,SABS,LLOYD’S,GL,NK,KR,ABS PRODUCTS CERTIFICATIONS
WITH TUV TYPE TESTING REPORT
WIDE PRODUCTS RANGE
ISO9001,ISO18001,OHSAS18001 SYSTEM CERTIFICATIONS
CNAS APPROVAL LABORATORY

type 61 3x35mm2+2x6mm2 Pilots +1x16mm2 Earth Core Yellow 640/1100V TRACKLESS MINING CABLE for South Africa

1 CONSTRUCTION Conductors Flexible class 5 comply to SANS 1411 – 1 from tinned annealed copper wires left lay Insulation Ethylene propylene thermosetting compound type RD 3 comply to SANS 1411-3.

Core of cable Three tinned copper/nylon braid screened power cores and one unscreened pilot core laid up in the right hand lay around rubber (RD1) filler centre.

Inner sheath Poly-chloroprene thermosetting compound type RS 6 comply to SANS 1411-3.

Re-enforcement An open nylon braid . Minimum 16 of nylon strings.

Outer sheath Poly-chloroprene thermosetting compound type RS 6 comply to SANS 1411-3 . Inner and outer sheath are bonded to provide proper torsional protection , black.

2 FEATURES

Excellent flexibility Min. ambient temperature -25 0 C , max. conductor temperature 90C

Marking for easy identification

3 APPLICATIONS

Electrically driven machines, movable electric apparatus in hazardous areas. For small pumps, fans, drills 2.5 mm2 . For shuttle cars 16 mm2 . Types 16, 25 mm2 suitable for reeling

Standard length cable packing 1000m on drums. Other forms of packing and delivery are available on request.

Insulation Material

R-EP-90

Application

Mining

Conductor Material

Copper

Jacket

CR or CPU Poly-chloroprene thermosetting compound type RS 6

We are China Supplier of African Market Mining Power Usage Rubber Sheathed Flexible Epr/CPE Oil Resistance Coal Mine Type 61 Ecc 25mm2 35mm2 Trailing Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
