Product Details

Model NO.

TECK90

Current

AC Cable

Insulation Material

XLPE

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Bare Copper Wire

Certification

cUL

Model

Teck90

Brand

Huatong Cables

Transport Package

Spools

Specification

14AWG 12AWG 10AWG 2AWG 500MCM 750MCM 2/0AWG 4/0AWG

Trademark

Huatong Cables

Origin

China

HS Code

8544492100

Production Capacity

4 Containers Per Month

Product Description

600V 1000V Teck90 Cables Copper or aluminium AIA

Structure:

Conductor: annealed bare copper wires, or compact aluminum 8000 series wires, class B.
Insulation: Cross-linked Polyethylene (XLPE) Type RW90

Color: Black, white for 2 conductors;

Black ,red, blue for 3 conductors;

Black, red, blue, white for 4 conductors.

Bonding conductor: annealed bare copper wires, or compact aluminum 8000 series wires, class B.
Inner Jacket: Flame-retardant and moisture resistant Polyvinyl Chloride (PVC)
Armour: Aluminum Interlock Armour (AIA);
Outer-jacket: Low-temperature, moisture and sunlight resistant Polyvinyl Chloride (PVC), black

Application:

Suitable for use in exposed or concealed wiring in dry or wet locations, in

ventilated or ladder type cable trays in dry or wet conditions, on walls or beams, or directly buried.

Suitable for use in hazardous locations: Class I – Groups A, B, C and D, Class II – Groups E, F and G, Class III – All Groups

Standard: CSA C22.2 No. 131, Type TECK90 cable;

CSA C22.2 No. 38, Thermoset insulated wires and cables (Type RW90)

Working temperature: -40ºC to +90ºC

Voltage: 600V, 1000V

# of Cond.	Conductor Size		Insulation Thickness	Inner Jacket Thickness	Approximate Diameters			Approx . Net Cable Weight	Approx . Copper Content
					Inner Jacket	Armor	Outer Jacket
	Power AWG or kcmil	Bonding AWG	inches	inches	inches	inches	inches	lb/kft	lb/kft
1	350	1	0.090	0.060	1.07	1.34	1.45	1910	1386
1	500	1/0	0.090	0.060	1.20	1.48	1.59	2515	1925
1	750	2/0	0.090	0.060	1.41	1.68	1.81	3648	2815
2	12	14	0.045	0.045	0.46	0.70	0.79	272	54
2	8	10	0.045	0.060	0.59	0.82	0.93	407	136
2	6	8	0.060	0.060	0.72	0.95	1.06	545	217
3	12	14	0.045	0.045	0.50	0.74	0.82	297	75
3	10	12	0.045	0.060	0.58	0.81	0.89	381	118
3	8	10	0.045	0.060	0.63	0.86	0.94	491	189
3	6	8	0.060	0.060	0.77	1.04	1. 13	644	300
3	4	8	0.060	0.080	0.90	1. 18	1.27	924	447
3	3	6	0.060	0.080	0.96	1.24	1.33	1026	582
3	2	6	0.060	0.080	1.03	1.30	1.39	1274	710
3	1	6	0.080	0.080	1. 18	1.46	1.55	1539	876
3	1/0	6	0.080	0.080	1.26	1.53	1.65	1852	1081
3	2/0	6	0.080	0.080	1.35	1.62	1.73	2165	1342
3	3/0	4	0.080	0.080	1.45	1.73	1.84	2571	1719
3	4/0	4	0.080	0.080	1.57	1.82	1.93	3196	2132
3	250	4	0.090	0. 110	1.77	2. 12	2.25	3830	2497
3	350	3	0.090	0. 110	1.98	2.33	2.46	4990	3475
3	500	3	0.090	0. 110	2.24	2.60	2.76	6674	4891
4	8	10	0.045	0.060	0.69	0.92	1.03	583	241
4	6	8	0.060	0.080	0.90	1. 17	1.28	838	382
4	4	8	0.060	0.080	1.00	1.27	1.35	1122	579
4	3	6	0.060	0.080	1.09	1.36	1.44	1359	749
4	2	6	0.060	0.080	1. 15	1.42	1.50	1580	920
4	2/0	6	0.080	0.080	1.49	1.76	1.87	2711	1761
4	3/0	4	0.080	0.080	1.61	1.85	1.96	3395	2248
4	4/0	4	0.080	0. 110	1.79	2.03	2. 14	4197	2799
4	250	4	0.090	0. 110	1.95	2.30	2.42	4828	3285
4	350	3	0.090	0. 110	2. 19	2.54	2.65	6399	4578
4	500	3	0.090	0. 110	2.48	2.83	3.02	8555	6466

Package:

For small sizes, ply-wood drums;

For big sizes, pine-wooden drums;
