Super High Quality Professional 5 Core 4mm Flexible Cable

Super High Quality Professional 5 Core 4mm Flexible Cable image

Get Latest Price Request a quote

Product Details

Model NO.

LV-YJV-5

Insulation Material

XLPE

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Copper Conductor

Certification

ISO, CCC, CE, VDE

Model

YJV

Brand

Huadong

Product Name

5 Core Copper Armoured Power Cable

Rated Voltage

0.6/1kv

Armour

Swa, Sta or Non Armoured

Size

16mm 25mm2 Ect

Other Cores

1 Core, 2 Core, 3 Core, 4 Core, 5 Core

Standards

Ieca, BS, DIN

MOQ

100m

Warranty

100% Qualified

Sample

Available

Color

Black/Blue or Others

Price

Get Within 12 Hours

Transport Package

by Wooden Drum

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

Super High Quality Professional 5 core 4mm flexible cable
Conductor: Stranded Copper
Insulation/Jacket: XLPE/PVC
Armoured: SWA(Steel Wire Armoured) / STA(Steel Tape Armoured) or Non-Armoured
Cores: 1, 2, 3, 4, 5, 3+1, 4+1, 3+2
Section Area: 1.5mm2-800mm2
Standard: IEC 60502, BS 7870, GB/T12706 or other.
Packaging: Iron Or Wooden Drum
Application: Building, Engineered, Railway, Plant construction, Shool, Hospital, Underground and so on.We can customize
the size according to your requirement.

No. of Cores	Conduct Cross Section Area	Stranding	Approx weight	Approx Overall Diameter	Nom. Max. DC-resist Conductor at 20ºC	Current Rating Laid Direct Amp
/	mm²	mm	kg/km	mm	Ω/Km	Amp
5	1.5	7/0.53	395	13.72	12.1	32
5	2.5	7/0.67	497	15.46	7.41	42
5	4	7/0.85	674	17.38	4.61	55
5	6	7/1.04	868	19.05	3.08	69
5	10	7/1.35	1197	22.06	1.83	92
5	16	7/1.70	1780	24.14	1.15	119
5	25	7/2.14	2435	28.4	0.727	152
5	35	7/2.52	2800	33	0.524	182
5	50	19/1.78	3850	38	0.387	217
5	70	19/2.14	5100	42.9	0.268	266
5	95	19/2.52	7700	52.1	0.193	319

	HIGH ELECTRICAL CONDUCTIVITY COPPER OR ALUMINIUM CONDUCTOR Copper or aluminium stranded(Class 2) conductors according to lEC 60228
HIGH RESISTANCE PVC/XLPE INSULATION Available with Cross-linked Polyethylene(XLPE)or Polyvinyl Chloride(PVC) insulation
	UV RESISTANCE & FLAME RETARDANT PVC JACKET Provided with flame retardant PVC jacket to pass flame propagation test to lEC60332-1
CUSTOMIZED DESIGNS Available in Armoured/Non-armoured and Shielded/Non-shielded constructions

Huadong Cable Shandong Co.,Ltd is an import and export trade company located in Jinan City, Shandong
Province, China, which is a branch of Henan Huadong Cable Group. Our factory occupied 50,000 square
meters.We specialize in 0.6-35KV power cables,overhead ABC cables, ACSR, AAAC,control cables, welding
cables, rubber cables, mining cables ect. We can provide high quality cables meet GB, IEC, BS,ICEA,
ASTM, DIN, VED and JIS strandards. What’s more, We can design cables according to your requirement.

We are China Super High Quality Professional 5 Core 4mm Flexible Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
