Product Details

Model NO.

RW90

Application

Heating

Conductor Material

Aluminum

Sheath Material

Crosslinking

Insulation Material

XLPE

Material Shape

Round Wire

Range of Application

Cold-Resistant

Certification

cUL

Brand

Huatong Cables

Working Temperature

-40~90c

Color

Black, White, Blue, Red...

Transport Package

Spool

Specification

14AWG 12AWG 10AWG 2AWG 500MCM 750MCM 2/0AWG 4/0AWG

Trademark

Huatong Cables

Origin

China

HS Code

8544492100

Production Capacity

12 Containers Per Month

Product Description

600V 1000V Type RW90 Wire

Structure:

1.Conductor: annealed bare copper wires, or compact aluminum 8000 series wires, class B.

2. Insulation: Heat and moisture resistant, low temperature Cross-Linked Polyethylene (XLPE)

Type RW90, -40°C to +90°C

Colour Coding: Black;

other colours available upon request.

Application:

For open wiring and raceways (except cable troughs and ventilated flexible cableway) in dry or wet locations.

For exposed wiring where exposed to weather with sunlight resistant insulation.

Approved for use with ceiling fixtures.

Standard: CSA–Standard C22.2 No.38

Working temperature: -40ºC to +90ºC

Voltage: 600V, 1000V

CUL file No: E466693

Marking on the surface of cable:

CU conductor: HUATONG CABLES C(UL) E466693 TYPE RW90 XLPE 90C DRY OR WET *AWG(**mm2) -40C SR ***V ****M

AL conductor: HUATONG CABLES C(UL) E466693 TYPE RW90 XLPE 90C DRY OR WET *AWG(**mm2) AA-8000 AL -40C SR ***V ****M

Specifications for AL conductor:

Conductor		Insulation thickness(mm)		Approx. OD (mm)
AWG/kcmil	Nos of strands	For 600V	For 1000V	For 600V	For 1000V
1X8	7	1.14	1.14	5.8	5.8
1X6	7	1.14	1.52	6.7	7.46
1X4	7	1.14	1.52	7.8	8.56
1X2	7	1.14	1.52	9.2	9.96
1X1/0	18	1.40	2.03	11.4	12.66
1X2/0	18	1.40	2.03	12.4	13.66
1X3/0	19	1.40	2.03	13.6	14.86
1X4/0	19	1.40	2.03	15.0	16.26
1X250	36	1.65	2.28	16.7	17.96
1X350	36	1.65	2.28	19.1	20.36
1X400	36	1.65	2.28	20.2	21.46
1X500	36	1.65	2.28	22.1	23.36
1X750	58	2.03	2.28	27.3	27.8

Packing Length: 300m, 600m or other length.

Plastic drums or plywood drums.
