Product Details

Model NO.

YJV22 YJV32 YJV72

Current

DC & AC

Insulation Material

XLPE

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Bare Copper Wire

Certification

ISO, CCC, CE, RoHS

Model

Yjv22 Yjv32

Brand

Xinxin

Color

Black /White

MOQ

500m

Conductor

Copper /Aluminum

Insulation

XLPE

Sheath

PVC

Payment

T/T L/C

Transport Package

Wooden Steel Drum

Specification

1.1*1.1*0.98m

Trademark

Shanghai Shenghua Cable Group

Origin

Shanghai, China

HS Code

8544492100

Production Capacity

100000

Product Description

Description:

CU/XLPE/STA/PVC, IEC 60502

IEC 60502, IEC 60228, GB/T 12706.1-2008.

CE, CCC, KEMA

0.6/1kV, suitable for underground laying

Constructions

Conductor: Circular stranded copper conductor, conforms to IEC 60228 class 2

Insulation: XLPE/A

Inner Covering: PVC

Armoring: Steel Tape

Sheath: PVC type ST₂ to IEC 60502, black

Note: Insulation color as per standards or at request

Applications

Suitable for U/G laying, Able to bear external mechanical forces but large pulling forces.

Standards

International: IEC 60502, IEC 60228

China: GB/T 12706.1-2008

Other standards such as BS,DIN and ICEA upon request

Technical data

Rated voltage: 0.6 / 1 kV

Max. Conductor Temp.: normal (90ºC), short circuit no more than 5 s (160ºC when section-area below 300mm², 140ºC when section-area above 300mm²)

Min. Ambient Temp.:The cable shall be pre heated if the ambient temperature is below 0ºC

Min. Bending Radius: 15 *(cable O.D)
