Shielded Rru 600V 2 X 10AWG 6mm Tfl Power Cable 600V

Shielded Rru 600V 2 X 10AWG 6mm Tfl Power Cable 600V image

Get Latest Price Request a quote

Product Details

Model NO.

2.5mm-16mm

Application

Underground

Conductor Material

Tinned Copper

Sheath Material

Flame Retardant Polyolefin

Insulation Material

Flame Retardant Polyolefin

Material Shape

Flat Wire

Range of Application

Flame Retardant

Certification

ISO9001, CE, CCC, RoHS, VDE, UL

Brand

Zenda

Name

Telecommunication Central Office Power Cable

Conductor

Tinned Copper Wire Conductor, Class 5

Screen

Al-Polyester Tape Screen

Braid

4.Tinned Copper Clad Aluminium Alloy Wire Braiding

Jacket

Flame Retardant Low Smoke Halogen Free Polyolefin

China Largest Manufacturer

Wholesale Price

Transport Package

Wooden Drum

Specification

TFL4923XX

Trademark

HT Cables

Origin

China

HS Code

8544492100

Production Capacity

200000/Week

Product Description

Telecommunication Central Office Power Cable RRU

Rated 75 or 90ºC dry, optionally 60, 75 or 90 ºC wet, 600V

Application

Halogen free, flexible connecting cable for fixed installation. Intended for power supply of telecom equipment, where there are requirements for low inductance and good temperature resistance. Grey jacket for indoor use. Black jacket is sunlight resistant, UV stabilized, for outdoor use.

Structure

Conductor

Stranded, tinned, annealed copper, IEC 60228 class 5. Three parallel cores to form a flat conductor.

Insulation

Flame retardant polyolefin black and grey.

Shield

Inner: aluminum polyester shield 100% coverage

Outer: Tinned copper Clad aluminum or tinned copper wire braid

Sheath

Flame retardant polyolefin , grey or black

Operating voltage

Max. 90 ºC,dry

Fire resistance

IEC 60332-3 cat C

UL 1685, Vertical tray

Standard:

UL2731, Telecommunication Central Office Power, Battery, and Distribution Cables

Technical data

Model	Conductors x size	Approx. Height x width	Weight Kg/100m		Max. DC resistance at 20ºC
Model	(mm2)	mm	With tinned copper wire braid	With tinned copper clad aluminium alloy braid	Ω/km
TFL 492322	2X2.5mm2(14AWG)	7.3*7.0	10	9.7	8.21
TFL 492324	2X6mm2(10AWG)	9.5*9.5	19.3	18.5	3.39
TFL 492324/0	2X6mm2(10AWG)	9.5*9.5	19.3	18.5	3.39
TFL 492325	2X10mm2 (8AWG)	10.5*11.5	29.2	27.9	1.95
TFL 492325/0	2X10mm2 (8AWG)	10.5*11.5	29.2	27.9	1.95
TFL 492326/0	2X16mm2 (6AWG)	11.8*13.6	42.2	40.8	1.24

Company information:

1 Location:

Hebei Huatong wires and cables group co., ltd. is Located inTangshan, 100 Km to TianjinXingang sea port, 150Km to the Capital city Beijing China.

2 About Huatong:

Founded in 1993 Registered capital: CNY294 Million Equal to: US$45 Million
Floor space: 420,000 square meter Employees: 2500 Production capacity:US$1000Million

3 Production and inspection facility:

Drawing machine : 50 sets
Conductor stranding machine: 30sets
CCV and CV extruding line: 30sets
Insulation and sheath extruding machine: 40sets
Cabling machine: 30sets
Braiding machine:40sets
Other auxiliary machine: 150stes
MV cable partial discharge
equipment: 4sets
Other test machine:100sets

4 Enterprise Principle:

Strengthening Huatong /Benefiting employees /Serving our country and society/Aiming to be a world-renowned enterprise

We are China Shielded Rru 600V 2 X 10AWG 6mm Tfl Power Cable 600V manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
