Rz1mz1-K XLPE Swa LSZH Armoured Low Smoke Zero Halogen Power Cable

Rz1mz1-K XLPE Swa LSZH Armoured Low Smoke Zero Halogen Power Cable image

Get Latest Price Request a quote

Product Details

Model NO.

RZ1MZ1-K

Current

DC & AC

Insulation Material

XLPE

Sheath Material

LSZH

Material Shape

Round Wire

Wire Core Material

Bare Copper Wire

Certification

ISO, CCC, CE, VDE

Brand

Huadong

Rated Voltage

0.6/1kv

Cores

1 2 3 4 5 Cores Ect

Size

1.5-300mm2

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

RZ1MZ1-K XLPE SWA LSZH Cable

Applications

Multi-core LSZH cable with steel wire armour (SWA). Power and auxiliary fixed wiring cables for use in power networks,underground, outdoor and indoor applications and for use in cable ducting. For installation where fire, smoke emission and toxic fumes create a potential threat to life and equipment.

Construction

Conductor Class 5 flexible copper conductor

Insulation XLPE (Cross-Linked Polyethylene)

Bedding Layer LSZH (Low Smoke Zero Halogen)

Armour Galvanized steel wires

Sheath LSZH (Low Smoke Zero Halogen)

Technical data

Working temperature -40° C to +90° C

Rated voltage 0.6/1 kV

Standard

UNE 21123-4, EN 60228, HD603,

Flame Retardant according to IEC/EN 60332-1,

IEC/EN 60332-3

Low Smoke Zero Halogen according to IEC/EN 60754-1/2,

IEC/EN 61034-1/2

Cable Parameter

NO.OF CORES	NOMINAL CROSS SECTIONAL AREA mm2	NOMINAL DIAMETER UNDER ARMOUR mm	NOMINAL OVERALL DIAMETER mm	NOMINAL WEIGHT kg/km	MINIMUM BENDING RADIUS mm
2	1.5	7.6	12.5	290	125
2	2.5	8.4	13.3	335	135
2	4	9.5	14.4	400	145
2	6	10.6	15.5	480	155
2	10	12.5	18.1	720	185
2	16	14.5	20.1	920	205
2	25	17.8	24.2	1370	245
2	35	20	26.4	1680	265
2	50	19.4	26.1	1835	265
2	70	23.2	29.9	2420	300
2	95	25.8	33.6	3175	340
2	120	29.2	37.4	3920	375
2	150	32.4	40.9	4680	410
2	185	35.6	45.4	5900	455
2	240	41.1	51.4	7485	515
3	1.5	8	13	320	130
3	2.5	8.9	13.9	375	140
3	4	10.1	15	450	150
3	6	11.3	16.2	545	165
3	10	13.3	18.9	830	190
3	16	15.5	21.1	1075	215
3	25	19.1	25.6	1640	255
3	35	21.7	28.2	2050	2851
3	50	23.3	30.91	2580	310
3	70	27.5	35.2	3365	355
3	95	30.6	38.81	4170	390
3	120	34.4	42.9	5070	430

1.You are manufacturer or trader ?
We are a professional cable&wire manufacturer with more than 20 years experience.Our factory located in jiaozuo city,henan province,china.

2.How can I get the quotation of the products ?
Pls send inquiry to us,we will reply you within 12 hours.

3.What does your company do regarding quality control?
1) all raw materials we selected are the highest quality.
2) professional and skillful workers care every details in handling the producing.
3) quality control department is specially responsible for quality checking in each process.

4.Do you provide OEM project service?
Yes,OEM & ODM order is warmly welcomed.
Our technical engineers can give you the professional suggestions.

5.Can I get the sample?
Yes,pls send inquiry to us,then our sales manager will arrange the samples for you.
