Round XLPE Renda Standard Export Drum Copper Wire RW90 Cable

UL44 Single Core Wire XLPE Insulated Copper Stranded 250mcm 350mcm Type Xhhw-2 Cable

1 Applicant of XHHW-2 cable:

 XHHW insulated wires are generally used in residential, commercial and industrial buildings and

 installations for the purpose of power distribution.

 The cable is manufactured in both copper and aluminum conductors and typically run in conduit or other approved raceways for services, feeder and circuit wiringXHHW insulation is rated by the Underwriters Laboratories (UL) to be suitable for use in dry locations up to 90 degrees Celsius, or wet locations up to 75 degrees Celsius.

2 Standard of XHHW-2 cable:

Listed by UL as Type XHHW-2 per Standard 44

3 Construction of XHHW-2 cable:

 XHHW-2 aluminum conductors are AlumaFlex AA-8000 series aluminum alloy, compact stranded.

The insulation is an abrasion, moisture and heat-resistant thermoset cross-linked polyethylene. Conductor sizes AWG 2 and larger listed and marked sunlight resistant in black only

4 Specification of XHHW-2 cable:

XHHW-2 conductors comply with the following:
• ASTM- All Applicable Standards
• UL Standard 44
• NOM-ANCE 90° C
• Federal Specification A-A-59544
• National Electrical Code, NFPA 70, 2011 Edition
• NEMA WC 70 Construction Requirements
• 500kcmil and larger SIMpull ® Product
• RoHS/Reach Compliant

5 Parameters for XHHW cable

Packing and shipping for XHHW-2 cable:

Standard export drum,500meters/drum,1000meters/drum or as your requirement.

Certificate:

We are one of China’s top-rank cable&wire manufacturers. Our products meet standards of GB, IEC DIN ASTM, JIS, NF, AS/NZS CSA GOST and so on. At the same time, we have obtained ISO9001, ISO14001, OHSAS18001, UL, CE, KEMA, TUV, Bureau Veritas, Lloyd, IEC, GL, SA, NK, KR certificates.
