Re-2X (St) Hswah-Pimf Instrument 20 Pairs X1.5 mm2 Copper Multi Pair Instrumentation Cable
Re-2X (St) Hswah-Pimf Instrument 20 Pairs X1.5 mm2 Copper Multi Pair Instrumentation Cable image
Get Latest Price Request a quote
You May Like
Product Details
Product Description
1-61 pairs PVC electrical instrument cable
Application : Instrumentation cables are designed to carry communication and control signals in a variety of installation
types including those found in the petrochemical industry
Pairs : 1-61 pairs
Standard : IEC 60228 or BS 6360
Conductor : Stranded copper conductor
Insulation : PE/XLPE/PVC
Armoring: SWA/STA/Galvanized steel wire or others
Sheath: PVC(polyvinyl chioride)
in electrical contact with a tinned annealed copper drain wire 0.5mm2
Individual screening: each pairs screened with aluminum/mytar tape, helically applied with the metallic side down in
electrical contact with a tinned annealed copper drain wire 0.5mm2
Cabling: twisted pairs are laid up together, if necessary filled with non-hygroscopic material compatible with the insulation.
Product Parameters:
|
No. of Pairs
|
Stranding
Dia |
Mom.
Insulation thickness |
Nom.
bedding thickness |
Approx.
dia.over bedding |
Nom.
Dia.of armour wire |
Nom.
Outer sheath thickness |
Approx.
Overall Dia |
Weight
Approx |
|
mm
|
mm
|
mm
|
mm
|
mm
|
mm
|
mm
|
kg/km
|
|
|
0.5mm²(solid)
|
||||||||
|
2
|
1/0.8
|
0.5
|
0.9
|
9.7
|
0.9
|
1.4
|
14.3
|
345
|
|
5
|
1/0.8
|
0.5
|
12
|
13.0
|
1.25
|
1.5
|
185
|
610
|
|
10
|
1/0.8
|
0.5
|
1.2
|
16.9
|
1.25
|
17
|
22.8
|
870
|
|
15
|
1/0.8
|
0.5
|
1.3
|
19.7
|
1.5
|
1.7
|
26.3
|
1265
|
|
20
|
1/0.8
|
0.5
|
1.3
|
22.3
|
1.6
|
1.8
|
29.1
|
1475
|
|
30
|
1/0.8
|
0.5
|
1.5
|
27.1
|
1.6
|
1.9
|
34.1
|
1915
|
|
50
|
1/0.8
|
0.5
|
2.0
|
35.0
|
2.0
|
2.2
|
43.4
|
3075
|
|
1.0 mm²(solid)
|
||||||||
|
2
|
1/1.13
|
0.6
|
1.1
|
11.9
|
0.9
|
1.5
|
16.7
|
435
|
|
5
|
1/1.13
|
0.6
|
1.2
|
15.4
|
1.25
|
1.6
|
21.1
|
755
|
|
10
|
1/1.13
|
0.6
|
1.3
|
20.5
|
1.6
|
1.8
|
27.3
|
1300
|
|
15
|
11.13
|
0.8
|
1.5
|
24.1
|
1.6
|
1.9
|
31.
|
1665
|
|
20
|
1/1.13
|
0.6
|
1.7
|
27.7
|
2.0
|
2.0
|
35.7
|
2240
|
|
30
|
1/1.13
|
0.6
|
2.0
|
33.7
|
2.0
|
2.2
|
42.1
|
2950
|
|
50
|
1/1.13
|
0.6
|
2.2
|
42.5
|
2.5
|
2.5
|
52.5
|
4639
|
|
0.5 mm²(flexible)
|
||||||||
|
2
|
16/0.2
|
0.6
|
1
|
11.2
|
0.9
|
1.5
|
16.0
|
400
|
|
5
|
16/0.2
|
0.6
|
1.2
|
14.5
|
1.25
|
1.6
|
20.2
|
680
|
|
10
|
16/0.2
|
0.6
|
1.3
|
19.3
|
1.6
|
1.8
|
26.1
|
1175
|
|
15
|
16/0.2
|
0.6
|
1.5
|
22.5
|
1.6
|
1.8
|
29.4
|
1420
|
|
20
|
16/0.2
|
0.6
|
1.5
|
25.7
|
1.6
|
19
|
327
|
1680
|
|
30
|
16/0.2
|
0.6
|
1.7
|
31.0
|
2.0
|
2.1
|
39.2
|
2415
|
|
50
|
16/0.2
|
0.6
|
2.2
|
39.9
|
2.5
|
2.4
|
48.7
|
3940
|
|
0.75mm²(flexible)
|
||||||||
|
2
|
24/0.2
|
0.6
|
1.1
|
12.1
|
0.9
|
1.5
|
16.9
|
437
|
|
5
|
24/0.2
|
0.6
|
12
|
15.r
|
1.25
|
1.6
|
21.4
|
755
|
|
10
|
24/0.2
|
0.6
|
1.3
|
20.9
|
1.6
|
17
|
27.5
|
1291
|
|
15
|
24/0.2
|
0.6
|
1.5
|
24.6
|
1.6
|
1.9
|
31.6
|
1680
|
|
20
|
24/0.2
|
0.6
|
1.5
|
27.9
|
1.6
|
19
|
34.9
|
2202
|
|
30
|
24/0.2
|
0.6
|
2.0
|
34.4
|
2.0
|
2.2
|
42.8
|
2880
|
|
50
|
24/0.2
|
0.6
|
2.2
|
43.5
|
2.5
|
2.5
|
53.5
|
4406
|
|
1.5mm²(stranded)
|
||||||||
|
2
|
7/0.52
|
0.6
|
1.2
|
13.6
|
1.25
|
1.6
|
19.3
|
635
|
|
5
|
7/0.52
|
0.6
|
1.3
|
17.7
|
1.6
|
1.7
|
24.3
|
1070
|
|
10
|
7/0.52
|
0.6
|
1.5
|
23.9
|
1.6
|
19
|
30.9
|
1605
|
|
15
|
7/0.52
|
0.6
|
1.7
|
28.0
|
2.0
|
2.0
|
36.0
|
2280
|
|
20
|
7/0.52
|
0.6
|
1.7
|
|
2.0
|
2.1
|
39.9
|
2730
|
|
30
|
7/0.52
|
0.6
|
2.0
|
38.6
|
2.5
|
2.5
|
48.5
|
4075
|
|
50
|
7/0.52
|
0.6
|
2.2
|
48.9
|
2.5
|
2.7
|
59.3
|
5765
|
Henan Huadong Cable Co., Ltd. Is a Joint Stock Enterprise Integrated in Cable Production, And Domestic & International
Trade,Founded in 1999, Located in Xiuwu Industrial Zone, Jiaozuo and Occupied 15,0000 Square Meters, With Advanced
20 Sets Equipments and 25 Sets Testing Machines, Annual Production Capacity Is over 15 Million Kilometers
We Mainly Produce and Export 1-35kv Power Cables, AAC,ACSR,AAAC Bare Conductors,Overhead Aerial Bundled ABC
Cables,Control Cables,Welding Cables, Rubber Cables, Mining Cables,Crane And Other Special Use Cables.
1.You are manufacturer or trader ?
We are a professional cable&wire manufacturer with more than 20 years experience.Our factory located in jiaozuo city,henan province,china.
2.How can I get the quotation of the products ?
Pls send inquiry to us,we will reply you within 12 hours.
3.What does your company do regarding quality control?
1) All raw materials we selected are the highest quality.
2) Professional and skillful workers care every details in handling the producing.
3) Quality control department is specially responsible for quality checking in each process.
4.Do you provide OEM project service?
Yes,OEM & ODM order is warmly welcomed.
Our technical engineers can give you the professional suggestions.
5.Can I get the sample?
Yes,pls send inquiry to us,then our sales manager will arrange the samples for you.
We are China Re-2X (St) Hswah-Pimf Instrument 20 Pairs X1.5 mm2 Copper Multi Pair Instrumentation Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
