PVC Industrial 4G1.5 4G10 4G4 4G16 4G25 4G35 4G95 4G50 4G70 Unarmoured U-1000 R2V Cable

PVC Industrial 4G1.5 4G10 4G4 4G16 4G25 4G35 4G95 4G50 4G70 Unarmoured U-1000 R2V Cable image

Get Latest Price Request a quote

Product Details

Model NO.

U1000 R2V

Current

DC & AC

Insulation Material

XLPE

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Bare Copper Wire

Certification

ISO, CE, VDE

Model

YJV

Brand

Huadong

Rated Voltage

0.6/1kv

Cores

1 2 3 4 5 Cores Ect

Size

1.5-1000mm2

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

U-1000 R2V/XV/RV Cable

Applications

These power cables are used for electricity supply in low voltage installation systems. They are well adapted to underground use in industrial applications with an additional mechanical protection. These cables can be fixed on cable trays, within conduits or fixed to walls.

Design

Conductor 1.5mm2 to 4mm2: Class 1 solid copper conductor*

6mm2 and above: Class 2 stranded copper conductor

*Class 2 stranded conductor available for these sizes on request

Insulation XLPE (Cross-Linked Polyethylene)

Bedding PVC (Polyvinyl Chloride)

Sheath PVC (Polyvinyl Chloride)

Characteristics

Voltage Rating Uo/U 0.6/1kV

Temperature Rating During installation -10°C to +50ºC

Fixed installation: -25°C to +90°C

Minimum Bending Radius

6 x overall diameter

Cable Parameter

Amount of cores	RM/RE*	Conductor size	Outer diameter mm	Weight kg/km	Part No
1	RM	16	10.5	195	29000
1	–	25	12.5	305	–
1	–	35	13.5	400	–
1	–	50	15	530	–
1	–	70	17	730	–
1	RM	95	19	1000	16936
1	RM	120	21	1260	16938
1	–	150	23	1545	–
1	RM	185	25.5	1925	16937
1	–	240	28.5	2645	16935
1	–	300	31	3075	–
1	–	400	32	3752	–
1	–	500	35	4806	–
1	–	630	42	6347	–
2	RE	1.5	9	100	29003
2	RE	2.5	10	128	29001
2	–	4	11	168	–
2	RM	6	12	231	29026
2	RM	10	14	333	29004
2	RM	16	16	516	29005
2	RM	25	20	790	29006
2	RM	35	22	1034	–
3G	RE	1.5	9	116	29007
3	RE	1.5	9	118	29002
3G	RE	2.5	10	152	29008
3G	RE	4	11	205	29009
3G	RM	6	11	284	29010
3G	RM	10	14	419	–
3G	RM	16	17	649	–
3	RM	50	26	1741	–
3	RM/35	50	33	2868	–
3	RM/50	70	33	2868	–
3	RM/50	95	36	3598	–
3	RM/70	120	49	6564	–
3	RM/70	150	49	6564	–
3	RM/70	185	49	6564	–
3	RM/95	240	55	8578	–
4G	RE	1.5	10	138	29011
4	–	1.5	10	138	–
4G	RE	2.5	11	183	29012
4	–	2.5	11	183	–
4G	RE	4	12	250	29013
4G	RM	6	14	350	29014
4	RM	6	14	350	–
4G	RM	10	16	521	29015
4	RM	10	16	521	16876
4	RM	16	18	808	16866
4G	RM	25	23	1261	29016
4	RM	25	23	1261	16877
4G	RM	35	26	1672	–
4	RM	35	26	1664	–
4G	RM	50	29	2231	–
4	RM	50	29	2231	–
4G	RM	70	34	3154	–
4	RM	70	34	3154	–
4	RM	95	38	4241	–
4	RM	120	42	5299	–
4	RM	240	59	10596	–
5G	RE	1.5	11	160	29017
5G	RE	2.5	12	215	29018
5G	RE	4	12	297	29019
5G	RM	6	15	428	29025
5G	RM	10	17	641	16895
5G	RM	16	21	993	16893
5G	RM	25	25	1540	29020
5G	RM	35	–	–	29021
7G	RE	1.5	12	204	29022
7G	–	2.5	13	279	–
12G	RE	1.5	15	321	29033
12G	–	2.5	16	460	–
19G	RE	1.5	17	464	29044
24G	–	1.5	19	609	–
27G	–	1.5	20	649	–
37G	–	1.5	22	833	–
