Professional Manufacturer Aluminum XLPE ABC Cable 4 Core 50mm2

Professional Manufacturer Aluminum XLPE ABC Cable 4 Core 50mm2 image

Get Latest Price Request a quote

Product Details

Model NO.

ABC-IEC

Insulation Material

XLPE

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Aluminium Conductor

Certification

ISO, CCC, CE, VDE

Model

ABC Cable

Brand

Huadong

Product Name

Aerial Bundled ABC Wire Cable

Rated Voltage

0.6/1kv

Cores

1,2,3,4,5 Cores

Standards

IEC 60502

MOQ

1000m

Warranty

100% Qualified

Sample

Available

Color

Black

Price

Get Within 12 Hours

Transport Package

by Wooden Drum

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

professional manufacturer aluminum xlpe abc cable 4 core 50mm2

Phase Conductor : Aluminium Conductor
Neutral Conductor : AAC/AAAC/ACSR
Insulation : XLPE/PE
Rated Voltage : 0.6/1KV
Cores : 1,2,3,4,5 3+1,4+1 Cores
Other Standards: ASTM/ NFC 33-209/BS 7870-5/AS/NZS or according to your requirement.
Application: The aerial bundled cables designed for overhead distribution lines have all conductors made of aluminium,
insulated with XLPE.Phase and neutral cores are laid up in a bundle with a left hand lay. Can be used for fixed installation
as overhead power lines up to 1000V.

IEC 60502 ABC(Aerial Bundle) Cable Parameter

Number of cores x nominal cross section	min. breaking load of conductor strand	Current rating in the air	Outer diameter	Total weight
mm^2	kN	A	mm	kg/km
1×16+1x 25 RM	6.4	61	15.3	160
3×16+1x 25 RM	6.4	61	19	290
3×25+1x 25 RM	6.4	84	23.2	400
3×35+1x 25 RM	6.4	104	25.6	500
3×50+1x 35 RM	8.9	129	30	680
3×70+1x 50 RM	12.1	167	34.9	920
3×95+1x 70 RM	18	209	40.6	1270
3×120+1x 70 RM	18	246	44.1	1510
3×150+1x 95 RM	24.2	283	49.2	1870
3×185+1×120 RM	30.8	332	54.9	2340
3×25+1×25+1×16 RM	6.4	84	23.2	470
3×35+1×25+1×16 RM	6.4	104	25.6	560
3×50+1×35+1×16 RM	8.9	129	30	740
3×70+1×50+1×16 RM	12.1	167	34.9	980
3×95+1×70+1×16 RM	18	209	40.6	1330
3×120+1×70+1×16 RM	18	246	44.1	1580
3×150+1×95+1×16 RM	24.2	283	49.2	1940
3×185+1×120+1×16 RM	30.8	332	54.9	2410
4×25 RM	3.5	84	21.5	420
4×35 RM	4.9	104	23.9	550
4×120+1×25 RM	16.8	246	43.8	1800
4×185+1×25 RM	25.9	332	50.7	2700

Henan Huadong Cable Co., Ltd. Is a Joint Stock Enterprise Integrated in Cable Production, And Domestic & International
Trade,Founded in 1999, Located in Xiuwu Industrial Zone, Jiaozuo and Occupied 15,0000 Square Meters, With Advanced
20 Sets Equipments and 25 Sets Testing Machines, Annual Production Capacity Is over 15 Million Kilometers
We Mainly Produce and Export 1-35kv Power Cables, AAC,ACSR,AAAC Bare Conductors,Overhead Aerial Bundled ABC
Cables,Control Cables,Welding Cables, Rubber Cables, Mining Cables,Crane And Other Special Use Cables.

We are China Professional Manufacturer Aluminum XLPE ABC Cable 4 Core 50mm2 manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
