Power Station 100m/Roll PV Solar 4mm2 DC Cable PV1-F with TUV Hot Sale
Power Station 100m/Roll PV Solar 4mm2 DC Cable PV1-F with TUV Hot Sale image
Get Latest Price Request a quote
You May Like
Product Details
Product Description
XLPO Insulation andJacket Single Core Solar Cable meet the varying needs of the solar industry,Applications include connecttion to module junction boxes,required cable routing in balance system integration rated 1000V.
Conductor:Fully annealed flexible tinned copper class5,VDE 0295/IEC60228
Insulation/Jacket Material :XLPO.
Norminal Voltage :AC U0/U=600/1000V,DC 1000/1800V
Temperature Rating:-40 degree to 90 degree.
Bending Radius :5xO.D
| Technical Specifications | |||||||
| Customer | Valuable customer | Sheet NO | S0518001 | ||||
| Standard | EN50618 | Construction Figure | |||||
| Construction | H1Z2Z2-K 1X4mm2 | ||||||
| Construction Item | Units | 4.0mm2 | |||||
| Construction | mm | 52/0.295±0.01 | |||||
| Material | — | Tinned copper wire | |||||
| O.D | mm | 2.40 | |||||
| Insulation | |||||||
| Material | — | XLPO | |||||
| Avg.Thick | mm | 0.70 | |||||
| Min.Thick | mm | 0.50 | Electric Characters | ||||
| O.D | mm | 3.95±0.15 | Voltage rating DC1500V | ||||
| Color | — | Black | Temperature rating:-40~90ºC | ||||
| Twisted Pair | Dielectric strength:AC-6.5kV/5min | ||||||
| Ins.Color | — | / | Spark test:AC-10kV/In the air | ||||
| Lay of Strand | mm | / | Conductor resistance:5.09ΩKM Max at20ºC | ||||
| O.D | mm | / | Weathering/UV-resistance:720h,No cracking | ||||
| Assemble | Thermal endurance properties: 25 Years | ||||||
| Filling | — | / | Physical Properties | ||||
| Lapping | — | / | |||||
| Drain.wire | — | / | Elongation of unaged values(%):≥125% | ||||
| Covering | Insulation Tensile strength of unaged values (N/mm2):≥6.5;Jacket Tensile strength of unaged values (N/mm2):≥8.0 |
||||||
| Material | — | / | |||||
| Avg.Thick | mm | / | |||||
| Min.Thick | mm | / | Aged in a full draft circulating air oven: 150±2.0ºC | ||||
| O.D | mm | / | Elongation of After aging(%):<=30% | ||||
| Color | — | / | Tensile strength of After aging:<=30% | ||||
| Armour | Ozone resistance:25±2ºC*24h No cracking | ||||||
| Construction | ‘ — |
/ | Cold bend test: -40±2ºC*16h No cracking | ||||
| Coverage | % | / | Cold impact test:-40ºC*16h/1000g;100mm No cracking | ||||
| Shield | Flame test:IEC 60332 | ||||||
| Material/ | — | / | Shanghai shenghua Cable Co.,Ltd | ||||
| Construction | — | / | |||||
| Coverage | % | / | |||||
| Jacket | |||||||
| Material | — | XLPO | |||||
| Avg.Thick | mm | 0.80 | |||||
| Min.Thick | mm | 0.60 | |||||
| O.D/ | mm | 5.55±0.2 | APPROVED | CHECKED | DESIGNED | ||
| Color/ | ‘ — |
Black | / | WKB | |||
| Surface/ | — | / | |||||
| Marking | APPROVED BY THE CLIENT | ||||||
| TÜV DC1500V H1Z2Z2-K 1×4.0mm2 Shanghai shenghua Cable Co., Ltd |
|||||||
We are China Power Station 100m/Roll PV Solar 4mm2 DC Cable PV1-F with TUV Hot Sale manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
